| 1. |
6549257
|
[4] |
HUB
|
L
|
| 2. |
700712602
|
[1] |
GEARBOX ASSY
|
L
see Figure 02-10 Superseded by part number: 700725501
|
| 3. |
700110416
|
[2] |
ANCHOR
|
HFI
|
| 4. |
409-7820
|
[8] |
BOLT,Hex Flg, 1/2" - 13 x 1 1/4", Spcl
|
CAS
Superseded by part number: 84209
|
| 5. |
6489231
|
[2] |
SPACER
|
CAS
|
| 6. |
383620
|
[2] |
BOLT
|
CAS
eye, WA
|
| 7. |
413-620
|
[2] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187207, 88011
|
| 8. |
496-11041
|
[2] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
hardened plain, 3/8" Superseded by part number: 86632588
|
| 9. |
230-4216
|
[2] |
LOCK NUT,3/8"-16, GA
|
CAS
Center Superseded by part number: 87039402
|
| 10. |
425-108
|
[4] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| 11. |
705541
|
[2] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
hardened plain, 1/2"
|
| 12. |
700708091
|
[2] |
SPHERICAL BEARING,34.93 mm ID x 72 mm OD x 38.89 mm
|
CAS
spherical Superseded by part number: 47577188, 47066
|
| 13. |
617863R1
|
[4] |
FLANGED BEARING
|
IH
bearing
|
| 14. |
433-612
|
[6] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 280430
|
| 15. |
231-5146
|
[6] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 16. |
700101761
|
[2] |
SHAFT
|
L
primary
|
| 17. |
178-878
|
[12] |
SET SCREW,Hex Soc, 5/16"-18 x 5/16"
|
CAS
set, cup point hex socket, 5/16"-18 x 5/16"
|
| 18. |
761114
|
[4] |
BUCKET TOOTH KEY
|
IH
1/4" x 3-5/8"
|
| 19. |
409-7812
|
[4] |
BOLT,Hex Flg, 1/2" - 13 x 3/4", Spcl
|
CAS
hex flange serrated, 1/2"-13 x 3/4" Superseded by part number: 86512178
|
| 20. |
7895410
|
[1] |
GEARBOX ASSY
|
CAS
see Figure 02-08 Superseded by part number: 700725501
|
