神钢零件查询(4D31-T) - MITSUBISHI DIESEL ENGINE (1/88-12/06) (01-017) - TURBO-CHARGER GENERAL Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
356 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME080098 | [1] | TURBOCHARGER | KOBTURBOCHARGER ASSY TD05-10A |
| 2. | VAMD050072 | [1] | GASKET | KOBGASKET |
| 3. | VAMH004054 | [3] | NUT | KOBNUT, FLANGE 10 Superseded by part number: 134868A1 |
| 8. | VAME080160 | [1] | PIPE PIPE, AIR INLET | PIPE PIPE, AIR INLET |
| 10. | VAMF140238 | [4] | SCREW | KOBBOLT, FLANGE 8 X 65 Superseded by part number: 134967A1 |
| 11. | VAME019485 | [1] | HOSE | KOBHOSE, RUBBER L = 65 |
| 12. | VAMH021326 | [2] | CLAMP | KOBCLAMP, BAND |
