| 1-19. | VAME080098 | [1] | TURBOCHARGER | KOBTURBOCHARGER ASSY TD05-10A, (49178005001) |
| 1. | VAME719618 | [1] | COVER, COMPR, (4916852100) | |
| 2. | VAME719621 | [1] | LOCK NUT | KOBNUT, LOCK, (4916842200) |
| 3. | VAME719601 | [1] | WHEEL, COMPR, (4916840300) | |
| 4. | VAME719585 | [1] | SNAP RING | KOBRING, SNAP, (4916823201) |
| 5. | VAME719590 | [1] | O-RING | KOBO-RING 50, (4916822100) |
| 6. | VAME719583 | [1] | INSERT | KOBINSERT, (4916022501) |
| 7. | VAME719582 | [1] | DEFLECTOR | KOBDEFLECTOR, OIL, (4916822202) |
| 8. | VAME719780 | [1] | PISTON RING | KOBRING, PISTON, (4917023100) |
| 9. | VAME719910 | [1] | SLEEVE | KOBSLEEVE, THRUST, (4917842100) |
| 10. | VAME719902 | [1] | THRUST BEARING | KOBBEARING, THRUST, (4917821500) |
| 10A. | VAME719912 | [1] | THRUST RING | KOBRING, THRUST, (4917842300) |
| 11. | VAME719900 | [2] | BEARING BEARING, (4917821100) | BEARING BEARING, (4917821100) |
| 11A. | VAME719904 | [2] | SNAP RING | KOBRING, SNAP, (4917822300) |
| 12. | VAME719627 | [1] | O-RING | KOBO-RING 100, (4916856100) |
| 13. | VAME719911 | [1] | BEARING HOUSING & PIN ASSY, (4917825700) | |
| 14. | VAME719575 | [1] | PLATE PLATE, TURBINE BACK, (4916816900) | PLATE PLATE, TURBINE BACK, (4916816900) |
| 15. | VAME719906 | [1] | PISTON RING | KOBRING, PISTON, (4917823100) |
| 16. | VAME719909 | [1] | SHAFT | KOBSHAFT & TURBINE WHEEL ASSY, (4917830100) |
| 17. | VAME719584 | [1] | SNAP RING | KOBRING, SNAP, (4916823101) |
| 18. | VAME719570 | [1] | COUPLING | KOBCOUPLING ASSY, (4916814001) |
| 19. | VAME719552 | [1] | HOUSING, TURBINE, (4917812700) | |
