凯斯零件查询(8420) - CASE IH ROUND BALER (1/88-12/00) (08-08) - HYDRAULIC CYLINDER ASSEMBLY (TAILGATE) (S/N CFH0054166 AND LATER) Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
494 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700711032
|
[1] |
CYLINDER ASSY.
|
L
hydraulic, complete
|
| 2. |
700707419
|
[1] |
PISTON
|
CAS
|
| 3. |
700707418
|
[1] |
JAM NUT
|
CAS
hex jam, 7/8"-14
|
| 4. |
700711111
|
[1] |
ROD
|
CAS
|
| 5. |
700711112
|
[1] |
GUIDE
|
CAS
|
| 6. |
413-628
|
[1] |
BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 72187210, 9706689
|
| 7. |
700711113
|
[1] |
CLEVIS
|
CAS
rod
|
| 8. |
425-106
|
[1] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 9. |
700711114
|
[1] |
SEAL KIT
|
L
seal, includes items marked with an asterisk on the illustration
|
