凯斯零件查询(8420) - CASE IH ROUND BALER (1/88-12/00) (08-06) - HYDRAULIC CYLINDER ASSEMBLY (TAILGATE) (S/N CFH0010501 THRU CFH0054165) Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
268 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700704934
|
[1] |
CYLINDER
|
CAS
ASSY. hydraulic, complete Superseded by part number: 700711078, 700711032
|
| 2. |
700704937
|
[1] |
ROD
|
CAS
WA piston
|
| 3. |
700704939
|
[1] |
RETAINER
|
CAS
|
| 4. |
700704935
|
[1] |
BUSHING
|
CAS
|
| 5. |
700704936
|
[1] |
SLEEVE CYLINDER
|
CAS
BARREL
|
| 6. |
700704938
|
[1] |
LOCK NUT
|
CAS
lock
|
| 7. |
700704942
|
[1] |
PISTON
|
CAS
|
| 8. |
700704941
|
[1] |
SEAL KIT
|
CAS
KIT repair, O-ring, includes items marked with an asterisk on the illustration
|
