凯斯零件查询(8420) - CASE IH ROUND BALER (1/88-12/00) (07-02) - JACK AND TOW CHAIN ASSEMBLY (SAFETY) Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
775 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
756007
|
[1] |
PIN
|
CAS
CHAIN ASSY., use with 745331 jack
|
| 1. |
700706640
|
[1] |
PIN
|
L
CHAIN ASSY., use with 700706826 jack
|
| 2. |
745315
|
[1] |
JACK
|
CAS
ASSY. lift Superseded by part number: 700709385
|
| 2. |
700709385
|
[1] |
JACK
|
IH
Assy, Lift
|
| 3. |
700706826
|
[1] |
JACK
|
IH
ASSY. lift
|
| 4. |
700705598
|
[1] |
CHAIN (CE)
|
CAS
safety
|
| 5. |
148558C1
|
[1] |
CLEVIS
|
IH
safety chain Superseded by part number: 1279163C1
|
| 6. |
413-1056
|
[1] |
BOLT,Hex, 5/8" - 11 x 3-1/2", Gr 5
|
CAS
Superseded by part number: 280119
|
| 7. |
230-41110
|
[1] |
LOCK NUT,5/8"-11, GA
|
CAS
lock, hex top, 5/8"-11, GR/B Superseded by part number: 85700693
|
| 8. |
D51609
|
[1] |
BALL JOINT
|
CAS
BEARING tongue
|
| 9. |
700101877
|
[1] |
SUPPORT
|
CAS
MOUNT, WA jack, Includes: Ref. 10
|
| 10. |
6227391
|
[1] |
TUBE,2" OD, 1.88" Length
|
CAS
jack
|
| 11. |
413-612
|
[2] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 72187204, 86500692
|
| 12. |
231-5146
|
[2] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 13. |
700119914
|
[1] |
MOUNTING PARTS
|
HFI
WA jack, Includes: Ref. 10
|
| 14. |
700711826
|
[1] |
JACK
|
CAS
KIT service, T.W.
|
