神钢零件查询(4D31-T) - MITSUBISHI DIESEL ENGINE (1/88-12/06) (02-004) - FAN AND PULLEY Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
421 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME080202 | [1] | FAN | KOBFAN, SUCTION TYPE PPG 550 |
| 2. | VAME008231 | [1] | SPACER | KOBSPACER L=50 |
| 3. | VAME080115 | [1] | PULLEY | KOBPULLEY, WATER PUMP PCD150 |
| 6. | VAMF140258 | [4] | BOLT,FLANGE(10X20) BOLT, FLANGE 10 X 20 | BOLT,FLANGE(10X20) BOLT, FLANGE 10 X 20 |
| 7. | VAMF241257 | [4] | BOLT | KOBBOLT, W/WSR 8 X 30 |
| 10. | VAME900745 | [1] | V-BELT V-BELT B L = 1170 | V-BELT V-BELT B L = 1170 |
