神钢零件查询(4D31-T) - MITSUBISHI DIESEL ENGINE (1/88-12/06) (02-009) - OIL LINE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
532 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME014547 | [1] | PIPE | KOBPIPE, OIL I/P |
| 2. | VAMH037279 | [1] | BOLT | KOBBOLT, EYE |
| . . | VAMF660063 | [2] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 30. | VAME080155 | [1] | PIPE | KOBPIPE, OIL TURBO INLET |
| 31. | VAMH038906 | [1] | HYD CONNECTOR | KOBCONNECTOR Superseded by part number: 133327A1 |
| 32. | VA3003638302 | [1] | CLAMP CLAMP | CLAMP CLAMP |
| 33A. | VAME920041 | [1] | SPACER | KOBSPACER L=17 |
| 34. | VAMF140029 | [1] | FLANGE BOLT | SMBOLT, FLANGE 8 X 30 |
| 38. | VAMH037719 | [1] | EYEBOLT | KOBBOLT, EYE |
| . . | VAMF660064 | [2] | PACKING | KOBGASKET 12 |
| 39. | VAME080262 | [1] | PIPE | KOBPIPE, OIL TURBO OUTLET |
| 44. | VAME014559 | [1] | GASKET | KOBGASKET Superseded by part number: VAME073842 |
| 45. | VAMH000999 | [2] | BOLT | KOBBOLT, FLANGE 6 X 12 |
| 46. | VAMF140227 | [2] | FLANGE BOLT | KOBBOLT, FLANGE 8 X 25 |
| 47. | VAME014532 | [1] | GASKET | KOBGASKET Superseded by part number: VAME013757 |
