神钢零件查询(4D31-T) - MITSUBISHI DIESEL ENGINE (1/88-12/06) (05-001) - INSTRUMENT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
530 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME019912 | [1] | INDICATOR | KOBINDICATOR, HEATER 24V |
| 2D. | VAMH052297 | [1] | CONNECTOR, 2P FEMALE | |
| 2G. | VAMH052377 | [1] | HYD CONNECTOR | KOBCONNECTOR, 1P FEMALE |
| 2J. | VAMH052356 | [1] | HYD CONNECTOR | KOBCONNECTOR, 1P FEMALE |
| 2K. | VAMB286874 | [1] | HYD CONNECTOR | KOBCONNECTOR, 2P FEMALE |
| 3A. | VAMH052042 | [1] | HYD CONNECTOR | KOBCONNECTOR, 6P FEMALE |
| 5A. | VAME049204 | [1] | RELAY | KOBRELAY, SAFETY, MEC Superseded by part number: ME049233 |
| 7. | VAME067625 | [1] | HEATER | KOBRELAY, HEATER, MEC Superseded by part number: VA3439000602 |
| . . | VAME067636 | [1] | FUSE | KOBFUSE 127A |
| 17. | VA3089005208 | [1] | SWITCH, STARTER KEY TYPE | |
