| 1-22. | VAME049165 | [1] | ALTERNATOR | KOBALTERNATOR ASSY, MEC 24V-25A, MEC A005T70383 |
| 1. | VAM502363 | [1] | NUT SET, MEC A529X04971 | |
| 2. | VAME700572 | [1] | PULLEY | KOBPULLEY BXI, MEC A628T47970 |
| 3. | VAMD607212 | [1] | SCREW SET, MEC A414X12771 | |
| 4-6. | VAME700548 | [1] | BRACKET | KOBBRACKET ASSY, FR, MEC A640T29470 |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONBRACKET, FR |
| 5. | VAM502367 | [1] | SCREW SET, MEC A414X10671 | |
| 6. | VAME700549 | [1] | BEARING BEARING, FR, MEC 5930P37301 | BEARING BEARING, FR, MEC 5930P37301 |
| 7-8. | VAME700741 | [1] | ROTOR ASSY ROTOR ASSY, MEC A880T36070 | ROTOR ASSY ROTOR ASSY, MEC A880T36070 |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONROTOR |
| 8. | VAME700552 | [1] | BEARING, REAR BEARING, RE, MEC 3930P61401 | BEARING, REAR BEARING, RE, MEC 3930P61401 |
| 13. | VAME700569 | [1] | STATOR | KOBSTATOR, MEC A363T26570 |
| 14-22. | VAME700742 | [1] | BRACKET | KOBBRACKET ASSY, RE, MEC A641T60870 |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONBRACKET, RE |
| 15A. | VAME700822 | [1] | TERMINAL | KOBTERMINAL SET, MEC A450X15471 |
| 17. | VAME700821 | [1] | NUT | KOBNUT SET, MEC A529X07071 |
| 19. | VAME700771 | [1] | RECITIFIER RECTIFIER ASSY, MEC A860T21470 | RECITIFIER RECTIFIER ASSY, MEC A860T21470 |
| 20-22. | VAME700571 | [1] | REGULATOR | KOBREGULATOR ASSY, MEC A866T06670 |
| 20. | NSS | [1] | NOT SOLD SEPARAT | CONREGULATOR |
| 21. | VAMD607373 | [2] | BRUSH, MEC A648002070 | |
| 22. | VAMD602227 | [2] | SPRING, BRUSH, MEC A389C01101 | |
