| 1. |
413-1228
|
[4] |
BOLT,Hex, 3/4" - 10 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 88725
|
| 2. |
493-41078
|
[4] |
LOCK WASHER,Ext Tooth, 3/4"
|
CAS
lock, external tooth, 3/4" Superseded by part number: 86512914
|
| 3. |
7701865
|
[4] |
BOLT,Flange, 1/2" - 13 x 1 3/4", SPL
|
HFI
SCREW hex flange serrated, 1/2"-13 x 2"
|
| 4. |
231-5148
|
[4] |
FLANGE NUT,Flg, USR, 1/2"-13
|
CAS
Superseded by part number: 72187069, 86512371
|
| 5. |
700101645
|
[2] |
QUICK MALE COUPLING
|
HFI
ANCHOR, WA
|
| 6. |
219-90
|
[2] |
LUBE NIPPLE,45 Degree Elbow, 1/4" -28 NPTF
|
CAS
ZERK, 1/4"-28 x 45° Superseded by part number: 87569
|
| 7. |
700117178
|
[1] |
ARM
|
CAS
WA tension, lower
|
| 8. |
413-836
|
[1] |
BOLT,Hex, 1/2" - 13 x 2-1/4", Gr 5
|
CAS
Superseded by part number: 87975
|
| 9. |
425-108
|
[2] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| 10. |
700117173
|
[1] |
ROD
|
CAS
indicator
|
| 11. |
6867394
|
[1] |
CHAIN (AG)
|
HFI
|
| 12. |
432-1012
|
[1] |
COTTER PIN,5/32" x 3/4"
|
CAS
5/32" x 3/4"
|
| 13. |
700117188
|
[1] |
ARM
|
HFI
gauge
|
| 14. |
437640
|
[2] |
BUSHING,12.95mm ID x 19.05mm OD x 12.7mm L
|
CAS
SPACER
|
| 15. |
700101866
|
[1] |
ANTI-WRAP PLATE
|
CAS
|
| 16. |
700101864
|
[1] |
STRAP
|
HFI
|
| 17. |
434-616
|
[5] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 80280503
|
| 18. |
231-5146
|
[5] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 19. |
700100927
|
[4] |
HUB
|
L
roller
|
| 20. |
413-440
|
[2] |
BOLT,Hex, 1/4" - 20 x 2-1/2", Gr 5
|
CAS
Superseded by part number: 87845
|
| 21. |
232-4114
|
[2] |
LOCK NUT,1/4"-20, GC
|
CAS
hex top, 1/4"-20, GR/B Superseded by part number: 280129
|
| 22. |
6869499
|
[2] |
DISC
|
HFI
serrated
|
| 23. |
8050825
|
[4] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
cylindrical Superseded by part number: F82059
|
| 24. |
700101637
|
[2] |
CONVEYOR ROLLER
|
L
TUBE ASSY., Includes: Ref. 23
|
