凯斯零件查询(8420) - CASE IH ROUND BALER (1/88-12/00) (05-02) - TAILGATE LATCH AND SAFETY STOP ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
580 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
230813
|
[1] |
WASHER
|
CAS
special
|
| 2. |
700101748
|
[2] |
PLATE
|
HFI
ARM, WA
|
| 3. |
700101744
|
[1] |
LATCH
|
L
WA left
|
| 4. |
433-824
|
[2] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
Superseded by part number: 280420, 72187237
|
| 5. |
495-21056
|
[2] |
WASHER,1/2"
|
CAS
wide plain, 1/2" Superseded by part number: 72187265, 80700
|
| 6. |
80679
|
[4] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 7. |
425-108
|
[4] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| 8. |
6287155
|
[2] |
SPACER
|
HFI
|
| 9. |
413-856
|
[2] |
BOLT,Hex, 1/2" - 13 x 3-1/2", Gr 5
|
CAS
Superseded by part number: 9637417
|
| 10. |
705541
|
[4] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
hardened plain, 1/2"
|
| 11. |
700101745
|
[1] |
LATCH
|
L
WA right
|
| 12. |
700101751
|
[2] |
SPACER
|
HFI
|
| 13. |
495-81070
|
[1] |
WASHER,1 1/32" x 1 1/2" x .120"
|
CAS
BUSHING machinery, 1" x 10 gauge Superseded by part number: 86624170
|
| 14. |
700101730
|
[1] |
STRAP
|
HFI
|
| 15. |
496-11041
|
[1] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
hardened plain, 3/8" Superseded by part number: 86632588
|
| 16. |
432-812
|
[1] |
COTTER PIN,3/4" OAL x 1/8" W
|
CAS
Superseded by part number: 80756
|
| 17. |
700101731
|
[1] |
ROD
|
HFI
|
| 18. |
413-536
|
[2] |
BOLT,Hex, 5/16" - 18 x 2-1/4", Gr 5
|
CAS
Superseded by part number: 86505972
|
| 19. |
230-4215
|
[4] |
NUT,5/16"-18, GA
|
CAS
Center
|
| 20. |
413-516
|
[2] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5
|
CAS
Superseded by part number: 9635884, 72187198
|
| 21. |
700101831
|
[2] |
COVER PLATE
|
HFI
WA safety
|
| 22. |
700101583
|
[2] |
CLAMP
|
HFI
WA mounting, stop
|
