斗山零件查询FRONT AXLE(4) B55W-1 Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
741 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
171.07.003.02
|
[6] |
PISTON
|
|
| 10. |
734.07.014.01
|
[2] |
BOLT;BLEEDING
|
|
| 11. |
171.07.011.01
|
[2] |
SPACER
|
|
| 12. |
171.07.610.05
|
[8] |
DISC;BRAKE
|
|
| 13. |
171.07.004.01
|
[1] |
DISC;BRAKE(LEFT)
|
|
| 14. |
171.07.004.02
|
[1] |
DISC;BRAKE(RIGHT)
|
|
| 2. |
738.07.009.01
|
[6] |
O-RING
|
|
| 3. |
738.07.010.01
|
[6] |
RING;BACK UP
|
|
| 4. |
171.07.009.02
|
[6] |
BOLT;ADJUSTING
|
|
| 5. |
171.07.010.01
|
[6] |
SPRING
|
|
| 6. |
001.05.1357
|
[6] |
O-RING
|
|
| 7. |
006.02.0193
|
[6] |
NUT
|
|
| 8. |
171.07.002.03
|
[8] |
DISC;INTERMEDIATE BRAKE
|
|
| 9. |
734.07.015.01
|
[2] |
PLUG
|
|
