| 1. |
52274
|
[3] |
WASHER
|
CAS
1-3/8 x 14 GA. NRMB Superseded by part number: 195-2139, 195-2139, NLS
|
| 2. |
52266
|
[2] |
WASHER
|
CAS
1-1/4 x 14 GA. NRMB Superseded by part number: 495-81205
|
| 3. |
495-81205
|
[3] |
WASHER,32.54mm ID x 50.8mm OD x 1.7mm Thk
|
CAS
1-1/4 x 18 GA. NRMB
|
| 4. |
761197
|
[1] |
WOODRUFF KEY,#23, 5/16" x 1 3/8"
|
CAS
Superseded by part number: 126-36
|
| 5. |
700120456
|
[1] |
SHAFT
|
HFI
ASSEMBLY Superseded by part number: 700126741
|
| 6. |
700708091
|
[1] |
SPHERICAL BEARING,34.93 mm ID x 72 mm OD x 38.89 mm
|
CAS
BEARING - spherical Superseded by part number: 47577188, 47066
|
| 7. |
712612
|
[2] |
FLANGE
|
NNA
- bearing Superseded by part number: 825620C1, 825620C1, 86900818
|
| 8. |
700120435
|
[1] |
SUPPORT
|
HFI
- bearing Superseded by part number: 700131801
|
| 9. |
61101
|
[1] |
KEY
|
HFI
1/4 x 1/4 x 1-3/4 KEY
|
| 10. |
7895410
|
[1] |
GEARBOX ASSY
|
CAS
GEARBOX ASSEMBLY Superseded by part number: 700725501
|
| 11. |
846642
|
[1] |
BUSHING
|
CAS
- reducer
|
| 12. |
7751605
|
[1] |
BREATHER
|
CAS
PLUG - vent Superseded by part number: 219-433
|
| . . |
703959
|
[4] |
BOLT,Hex, 1/2" - 13 x 1", Gr 5, Full Thd
|
CAS
1/2-13 x 1 C
|
| . . |
7702038
|
[1] |
SCREW,Hex, 1/2" - 13 x 3", Gr 5
|
CAS
1/2-13 x 3 C Superseded by part number: 87339
|
| . . |
7700065
|
[3] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 x 3/4 RHSNB Superseded by part number: 280430
|
| . . |
7771272
|
[4] |
BOLT,Hex Serr, 1/2" - 13 x 3/4"
|
CAS
1/2-13 x 3/4 HFSS Superseded by part number: 86512178
|
| . . |
86516876
|
[5] |
1/2-13 H
|
COVER
|
| . . |
700047
|
[3] |
BOLT
|
CAS
3/8-16 HFSLN Superseded by part number: 80280503
|
| . . |
80679
|
[5] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
