凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (2-10) - GEAR BOX ASSEMBLY, (7895410 GEARBOX ASSEMBLY COMPLETE), (S.N Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
536 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700703554
|
[1] |
SHAFT
|
CAS
- long
|
| 2. |
753574
|
[1] |
KEY
|
CAS
- tapered
|
| 3. |
711242
|
[1] |
BEARING CUP
|
CAS
CUP - bearing Superseded by part number: 47923369
|
| 4. |
753418
|
[1] |
SHIM
|
HFI
(.002)
|
| 4. |
753426
|
[1] |
SHIM
|
CAS
(.005)
|
| 4. |
753434
|
[1] |
SHIM
|
CAS
(.010)
|
| 5. |
757229
|
[1] |
RING, SNAP
|
CAS
RING - retainer
|
| 6. |
700703549
|
[1] |
SHAFT
|
CAS
- short
|
| 7. |
757153
|
[2] |
SEAL
|
CAS
Superseded by part number: 701519
|
| 8. |
1702216
|
[6] |
GASKET
|
CAS
- aluminum (.015)
|
| 8. |
1702224
|
[3] |
GASKET
|
CAS
- aluminum (.005)
|
| 8. |
1702232
|
[3] |
GASKET
|
CAS
- aluminum (.003)
|
| 9. |
710350
|
[3] |
BRACKET,69.037 mm OD x 15.875 mm
|
CAS
- bearing Superseded by part number: ST991
|
| 10. |
757088
|
[3] |
CONE
|
CAS
- bearing Superseded by part number: 86576984
|
| 11. |
8806317
|
[1] |
GEAR-SET
|
CAS
GEAR SET (MATCHED) AND TWO TAPERED KEYS
|
| 12. |
711507
|
[1] |
ROLLER BEARING,31.77 mm ID x 16.764 mm
|
IH
CONE - bearing Superseded by part number: 84356153
|
| 13. |
757054
|
[1] |
CAP
|
CAS
- blank
|
| 14. |
7037518
|
[3] |
O-RING,0.103" Thk x 3.987" ID, -155, Cl 5, 75 Duro
|
CAS
Superseded by part number: 9828498
|
| 15. |
7751605
|
[1] |
BREATHER
|
CAS
PLUG - vented Superseded by part number: 219-433
|
| 16. |
700100292
|
[1] |
HOUSING
|
CAS
|
| 17. |
757120
|
[2] |
CAP
|
CAS
|
| . . |
703579
|
[24] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5, Full Thd
|
CAS
5/16-18 x 1 C
|
| . . |
7772197
|
[24] |
SCREW,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
CAS
M8 x 1.25 x 25 C Class 8.8 Superseded by part number: 43127
|
| . . |
700700324
|
[24] |
SPRING WASHER
|
CAS
M8 L Superseded by part number: 83990583
|
