凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (2-22) - DRIVE ASSEMBLY (PICKUP BELT TIGHTENER) Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
812 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700120925
|
[1] |
SUPPORT
|
HFI
ARM - idler
|
| 2. |
758789
|
[1] |
COIL SPRING
|
L
SPRING - tension
|
| 3. |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
EYEBOLT
|
| 4. |
705582
|
[2] |
WASHER
|
CAS
5/8 HARDENED PLAIN WASHER Superseded by part number: 396-21066, 396-21066, NLS
|
| 5. |
6484257
|
[1] |
SPACER
|
CAS
|
| 6. |
662958R91
|
[1] |
PULLEY
|
IH
IDLER - flat
|
| 7. |
705525
|
[2] |
WASHER
|
CAS
5/16 HARDENED PLAIN WASHER Superseded by part number: 86637953
|
| 8. |
705566
|
[2] |
WASHER
|
IH
3/4 HARDENED PLAIN WASHER
|
| 9. |
62075
|
[1] |
PIN
|
CAS
1/8 x 3/4 COTTER PIN Superseded by part number: 80756
|
| 10. |
700120927
|
[1] |
SPACER
|
HFI
|
| 11. |
296608
|
[1] |
BOLT,3/8" - 16 x 2"
|
CAS
EYEBOLT
|
| 12. |
700120453
|
[1] |
ROD
|
HFI
- declutcher
|
| . . |
7701683
|
[1] |
BOLT,Hex, 5/8" - 11 x 3", Gr 5
|
CAS
5/8-11 x 3 C Superseded by part number: 87338
|
| . . |
703389
|
[1] |
|
HFI
3/4-10 x 9 Superseded by part number: 413-12144
|
| . . |
704015
|
[2] |
NUT,5/16"-18, G5
|
CAS
5/16-18 H Superseded by part number: 425-105, 425-105, 9635082
|
| . . |
704023
|
[5] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| . . |
704130
|
[1] |
NUT,5/8"-11, G5
|
CAS
5/8-11 H Superseded by part number: 280374
|
| . . |
704528
|
[1] |
NUT,3/4"-10, G5
|
CAS
3/4-10 H Superseded by part number: 280954
|
| . . |
705061
|
[1] |
PLUG
|
NNA
5/8" Superseded by part number: 492-11062
|
| . . |
705111
|
[1] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
