| 1. |
700120461
|
[1] |
HOUSING
|
HFI
BEARING ASSEMBLY (includes item 2)
|
| 2. |
714113
|
[1] |
SPHERICAL BEARING,1.75" ID x 85 mm OD
|
CAS
BEARING - spherical Superseded by part number: 47577169, 47577157
|
| 3. |
700120454
|
[1] |
SHAFT
|
HFI
|
| 4. |
6549257
|
[1] |
HUB
|
L
COUPLER
|
| 5. |
69773
|
[3] |
LUBE NIPPLE
|
CAS
5/16-18 x 5/16 CPHSSS Superseded by part number: 178-878
|
| 6. |
761114
|
[1] |
BUCKET TOOTH KEY
|
IH
1/4 x 1/4 x 3-5/8 KEY
|
| 7. |
700120936
|
[2] |
SUPPORT
|
HFI
- block
|
| 8. |
NLS
|
[3] |
NO LONGER SERVICED
|
BAS
5/8 HARDENED PLAIN WASHER
|
| 9. |
541857R92
|
[2] |
SPROCKET,15T
|
IH
SPROCKET - idler, 15 tooth
|
| 10. |
760728
|
[2] |
BLOCK ASSY.
|
L
BLOCK - tightener
|
| 11. |
705541
|
[4] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 12. |
61432
|
[1] |
BUCKET TOOTH KEY
|
IH
3/8 x 3/8 x 1-1/2 GIB KEY
|
| 13. |
700101759
|
[1] |
SPROCKET
|
L
- 39 tooth
|
| 14. |
700119916
|
[1] |
MOUNTING PARTS
|
HFI
MOUNT - tightener
|
| . . |
703736
|
[2] |
BOLT,Hex, 1/2" - 13 x 2 3/4", Gr 5
|
CAS
1/2-13 x 2-3/4 C
|
| . . |
700013
|
[4] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 RHSNB
|
| . . |
433-816
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5
|
CAS
1/2-13 x 1 RHSNB Superseded by part number: 280486
|
| . . |
7870223
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 4", Gr 5
|
CAS
5/8-11 x 4 RHSNB Superseded by part number: 280461
|
| . . |
7703432
|
[1] |
BOLT,Hex, Serr, 3/8" - 16 x 3/4"
|
CAS
3/8-16 x 3/4 HFSS Superseded by part number: 255918
|
| . . |
86516876
|
[2] |
1/2-13 H
|
COVER
|
| . . |
704130
|
[2] |
NUT,5/8"-11, G5
|
CAS
5/8-11 H Superseded by part number: 280374
|
| . . |
231-5145
|
[4] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
5/16-18 HFSLN Superseded by part number: 72187067, 145458
|
| . . |
704247
|
[1] |
NUT
|
CAS
3/8-16 HFSLN Superseded by part number: 231-5146, 231-5146, 280736, 231-5146, 280736, 692965, 231-5146, 280736, 692965, 87362
|
| . . |
704254
|
[4] |
NUT,Flg, USR, 1/2"-13
|
CAS
1/2-13 HFSLN Superseded by part number: 86512371
|
| . . |
80679
|
[2] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| . . |
705061
|
[2] |
PLUG
|
NNA
5/8" Superseded by part number: 492-11062
|
