凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (3-06) - PICKUP ROTOR ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
508 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700120511
|
[1] |
ROTOR
|
HFI
WA - pickup
|
| 2. |
701367
|
[3] |
HEX SOC SCREW,3/8"-16 x 2 1/4"
|
CAS
3/8-16 x 2-1/4 HSHCS Superseded by part number: 61-636
|
| 3. |
710392 HCH
|
[6] |
BEARING - spherical
|
|
| 4. |
700108622
|
[6] |
FLANGED BEARING
|
L
FLANGE - bearing
|
| 5. |
702700045
|
[3] |
LOCK NUT
|
L
1/2-20 SPIRAL LOCK NUT
|
| 6. |
700705612
|
[3] |
CAM FOLLOWER
|
L
BEARING - cam follower Superseded by part number: 86536275
|
| 7. |
432-1632
|
[6] |
COTTER PIN,1/4" x 2"
|
CAS
1/4 x 2 COTTER PIN Superseded by part number: 88182
|
| 8. |
700108618
|
[3] |
ARM
|
L
CRANK WA
|
| . . |
700125941
|
[3] |
CRANK
|
HFI
WA
|
| 9. |
700709210
|
[27] |
TOOTH
|
L
TINE - double Superseded by part number: 47518553
|
| 10. |
700120390
|
[3] |
ANGLE BAR
|
IH
ANGLE - tine
|
| . . |
7700065
|
[12] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 x 3/4 RHSNB Superseded by part number: 280430
|
| . . |
700047
|
[27] |
BOLT
|
CAS
3/8-16 x 1 RHSNB Superseded by part number: 80280503
|
| . . |
704023
|
[12] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| . . |
704734
|
[27] |
FLANGE NUT,Flg, 3/8"-16
|
IH
3/8-16 HFTLN Superseded by part number: 86521609
|
| . . |
88902
|
[3] |
NUT,3/8"-16
|
NH
3/8-16 HCLN
|
| . . |
705038
|
[12] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
