凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (3-04) - PICKUP AND WRAPPER ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
319 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700120515
|
[1] |
SUPPORT
|
HFI
WRAPPER - end, left
|
| 2. |
700120759
|
[17] |
GUARD
|
L
WRAPPER
|
| 3. |
700120516
|
[1] |
SUPPORT
|
HFI
WRAPPER - end, right
|
| 4. |
700116125
|
[1] |
HOUSING
|
CAS
TRACK - cam
|
| 5. |
700120502
|
[1] |
FRAME
|
HFI
WA - pickup
|
| 6. |
700708091
|
[2] |
SPHERICAL BEARING,34.93 mm ID x 72 mm OD x 38.89 mm
|
CAS
BEARING - spherical Superseded by part number: 47577188, 47066
|
| 7. |
617863R1
|
[4] |
FLANGED BEARING
|
IH
- bearing
|
| 8. |
6284046
|
[1] |
PINION
|
L
SPROCKET - 50 P, 45 tooth
|
| 9. |
761213
|
[1] |
KEY
|
CAS
5/16 x 5/16 x 1-1/2 GIB KEY Superseded by part number: Q3929
|
| . . |
703249
|
[3] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| . . |
702035
|
[2] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 x 1-1/4 C
|
| . . |
7701899
|
[1] |
BOLT,Hex, 3/8" - 16 x 2 1/2", Gr 5
|
CAS
3/8-16 x 2-1/2 C Superseded by part number: 87936
|
| . . |
700013
|
[23] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 RHSNB
|
| . . |
700047
|
[3] |
BOLT
|
CAS
3/8-16 x 1 RHSNB Superseded by part number: 80280503
|
| . . |
703132
|
[19] |
SERRATED SCREW
|
CAS
5/16-18 x 3/4 HFSS Superseded by part number: 145913
|
| . . |
704023
|
[3] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| . . |
704239
|
[42] |
FRONT AXLE
|
NNA
5/16-18 HFSLN Superseded by part number: 231-5145, 231-5145, NLS
|
| . . |
704247
|
[3] |
NUT
|
CAS
3/8-16 HFSLN Superseded by part number: 231-5146, 231-5146, 280736, 231-5146, 280736, 692965, 231-5146, 280736, 692965, 87362
|
| . . |
705038
|
[6] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
