凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (4-04) - MONITOR BOX ASSEMBLY, (700120396 MONITOR BOX ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
282 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700709235
|
[1] |
CABLE
|
CAS
- electrical
|
| 2. |
700708916
|
[1] |
DECAL
|
HFI
- monitor
|
| 3. |
7020480
|
[1] |
BOX, FUSE
|
CAS
HOLDER - fuse Superseded by part number: 578489
|
| 4. |
700707598
|
[1] |
WIRE HARNESS
|
IH
CABLE - electrical
|
| 5. |
702700050
|
[1] |
FUSE
|
IH
(5 AMP) Superseded by part number: 86705048
|
| 6. |
700710307
|
[1] |
BULB
|
IH
(12 VOLT)
|
| 7. |
700707759
|
[1] |
INDICATOR
|
IH
LAMP - pilot
|
| 8. |
700708918
|
[1] |
DECAL
|
HFI
- monitor
|
| 9. |
700707458
|
[1] |
INDICATOR
|
IH
LAMP - indicator, green
|
| 10. |
701607
|
[4] |
BRACKET
|
CAS
1/4-20 x 1/2 HWHTCTS Superseded by part number: 281-1478, 281-1478, NLS
|
| 11. |
700120396
|
[1] |
BOARD, PRINTED CIRCU
|
HFI
CONTROL BOX ASSEMBLY COMPLETE (includes all items except 1, 4, and 13)
|
| 12. |
A59457
|
[1] |
BRACKET
|
CAS
- socket Superseded by part number: 847590
|
| 13. |
6866081
|
[1] |
BRACKET
|
CAS
SPADE - socket
|
| 14. |
700704212
|
[2] |
SELF-TAP SCREW
|
CAS
NO. 4-24 x 3/8 SPHTFTS
|
| 15. |
700703984
|
[1] |
INDICATOR
|
IH
- audio
|
| 16. |
700706896
|
[1] |
SWITCH
|
CAS
|
| 17. |
700707757
|
[2] |
CONTAINER
|
CAS
RECEPTACLE - electrical, 4 pin
|
| . . |
7883325
|
[2] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
700707770
|
[8] |
SCREW
|
HFI
NO. 4-40 x 3/8 CRPHMS Superseded by part number: 182-5
|
| . . |
700701068
|
[2] |
SCREW
|
CAS
5/16-18 x 1/2 CRPHMS Superseded by part number: 1270468C1
|
| . . |
700701035
|
[8] |
HARDWARE
|
HFI
NO. 4-40 H Superseded by part number: 280385
|
| . . |
704239
|
[4] |
FRONT AXLE
|
NNA
5/16-18 HFSLN Superseded by part number: 231-5145, 231-5145, NLS
|
| . . |
700701036
|
[8] |
LOCK WASHER,#4
|
HFI
Washer, Lock, #4 Superseded by part number: 84877
|
