凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (7-02) - HITCH, JACK AND TOW CHAIN ASSEMBLY (SAFETY) Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
509 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
703249
|
[8] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| 2. |
80702
|
[8] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
3/8 HARDENED PLAIN WASHER
|
| 3. |
705038
|
[8] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
| 4. |
704023
|
[8] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| 5. |
700120443
|
[2] |
SUPPORT
|
HFI
STRAP - reinforcement
|
| 6. |
700120423
|
[1] |
TRAILER HITCH
|
HFI
HITCH WA
|
| 7. |
6471791
|
[1] |
BOLT
|
L
1/8 x 5 BOLT - hitch
|
| 8. |
705574
|
[4] |
WASHER,1 1/8" x 2" x .156", HDN
|
CAS
|
| 9. |
432-1232
|
[1] |
COTTER PIN,3/16" OD x 2" L
|
CAS
3/16 x 2 COTTER PIN Superseded by part number: 87400
|
| 10. |
704973
|
[1] |
SLOTTED NUT,1"-8, G5
|
CAS
1-8 SLOTTED HEX NUT Superseded by part number: 87343900
|
| 11. |
7701550
|
[1] |
BOLT,Hex, 5/8" - 11 x 3 1/2", Gr 5
|
CAS
5/8-11 x 3-1/2 C Superseded by part number: 413-1056, 413-1056, NLS
|
| 12. |
704924
|
[1] |
NUT
|
CAS
5/8-11 HTLN GR/B Superseded by part number: 85700693
|
| 13. |
700117928
|
[1] |
CLEVIS
|
CAS
- safety chain Superseded by part number: 1279163C1
|
| 14. |
700705598
|
[1] |
CHAIN (CE)
|
CAS
SAFETY - chain
|
| 15. |
D51609
|
[1] |
BALL JOINT
|
CAS
BEARING - tongue
|
| 16. |
700120427
|
[1] |
SUPPORT
|
HFI
ASSEMBLY - jack
|
| 17. |
700706826
|
[1] |
JACK
|
IH
- lift (includes items 18 and 19)
|
| 18. |
700711826
|
[1] |
JACK
|
CAS
KIT - service, T.W.
|
| 19. |
700706640
|
[1] |
PIN
|
L
AND CHAIN ASSEMBLY
|
