凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (7-04) - WHEEL AND HUB ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
321 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T52730
|
[6] |
WHEEL BOLT
|
IH
9/16-18 x 1-1/8 WHEEL BOLT Superseded by part number: 86628557
|
| 2. |
700707924
|
[1] |
RIM
|
CAS
WHEEL - 15 inch Superseded by part number: A57879
|
| 3. |
D143405
|
[1] |
CAP
|
CAS
- hub Superseded by part number: 137395
|
| 4. |
274760
|
[1] |
7/8-14 SLOTTED HEX NUT
|
SEAL KIT
|
| 5. |
26971
|
[1] |
WASHER
|
CAS
|
| 6. |
712166
|
[1] |
CONE
|
CAS
- bearing, outer Superseded by part number: 86516471
|
| 7. |
712208
|
[1] |
CUP
|
CAS
- bearing, outer Superseded by part number: 86516462
|
| 8. |
712182
|
[1] |
BEARING CUP,3.265" OD
|
CAS
CUP - bearing, inner Superseded by part number: 86900365
|
| 9. |
300426R91
|
[1] |
BEARING ASSY,45.618 mm ID x 25.4 mm
|
IH
CONE - bearing, inner Superseded by part number: 512725
|
| 10. |
744193
|
[1] |
SEAL
|
CAS
- grease Superseded by part number: 491715R91
|
| 11. |
703793
|
[4] |
BOLT,Hex, 5/8" - 11 x 1 3/4", Gr 5, Full Thd
|
CAS
5/8-11 x 1-3/4 C Superseded by part number: 9627896
|
| 12. |
705061
|
[4] |
PLUG
|
NNA
5/8" Superseded by part number: 492-11062
|
| 13. |
704130
|
[4] |
NUT,5/8"-11, G5
|
CAS
5/8-11 H Superseded by part number: 280374
|
| 14. |
700120439
|
[1] |
SPINDLE
|
HFI
WA Superseded by part number: 700152665
|
| 15. |
026690
|
[1] |
HUB
|
CAS
(includes items 6 and 7)
|
| 16. |
432-824
|
[1] |
COTTER PIN,1/8" x 1 1/2"
|
CAS
1/8 x 1-1/2 COTTER PIN Superseded by part number: 80708
|
| 17. |
A38261
|
[1] |
VALVE
|
CAS
STEM - valve Superseded by part number: 196033
|
