凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (7-06) - SHIELDS ASSEMBLY (DRIVELINE AND TWINE BOX) Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
608 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700120571
|
[1] |
PANEL
|
HFI
- side, left
|
| 2. |
705533
|
[2] |
WASHER
|
NNA
3/8 HARDENED PLAIN WASHER Superseded by part number: 496-11041, 496-11041, 80702
|
| 3. |
160127
|
[2] |
SPACER
|
HFI
|
| 4. |
700122596
|
[1] |
SHIELD
|
HFI
- pto
|
| 5. |
700120572
|
[1] |
PANEL
|
HFI
- side, right
|
| 6. |
700120570
|
[1] |
PANEL
|
HFI
- floor
|
| 7. |
700120573
|
[1] |
DIVIDER
|
HFI
- twine box
|
| 8. |
700120462
|
[1] |
SHIELD
|
HFI
Superseded by part number: 700131811
|
| 9. |
700120569
|
[1] |
COVER
|
HFI
- twine box
|
| 10. |
700120565
|
[1] |
ROD
|
HFI
PIN - hinge
|
| 11. |
700120567
|
[1] |
SHIELD
|
HFI
- drive line
|
| 12. |
700120558
|
[2] |
SUPPORT
|
HFI
PIVOT - support
|
| . . |
703249
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| . . |
703132
|
[4] |
SERRATED SCREW
|
CAS
5/16-18 x 3/4 HFSS Superseded by part number: 145913
|
| . . |
7772700
|
[10] |
BOLT,Hex Serr, 3/8" - 16 x 1/2"
|
HFI
3/8-16 x 1/2 HFSS Superseded by part number: 50215
|
| . . |
7703432
|
[3] |
BOLT,Hex, Serr, 3/8" - 16 x 3/4"
|
CAS
3/8-16 x 3/4 HFSS Superseded by part number: 255918
|
| . . |
704023
|
[2] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| . . |
704239
|
[4] |
FRONT AXLE
|
NNA
5/16-18 HFSLN Superseded by part number: 231-5145, 231-5145, NLS
|
| . . |
704247
|
[13] |
NUT
|
CAS
3/8-16 HFSLN Superseded by part number: 231-5146, 231-5146, 280736, 231-5146, 280736, 692965, 231-5146, 280736, 692965, 87362
|
| . . |
705038
|
[2] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
