凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (7-10) - SHIELDS ASSEMBLY (LOWER-LEFT) Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
371 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700120549
|
[1] |
SHIELD
|
HFI
- side, left, lower
|
| 2. |
700119907
|
[1] |
HINGE
|
HFI
|
| 3. |
700120546
|
[1] |
SUPPORT
|
HFI
- shield, front Superseded by part number: 700131985
|
| 4. |
6556518
|
[1] |
PIN
|
HFI
- hinge
|
| 5. |
80702
|
[5] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
3/8 HARDENED PLAIN WASHER
|
| 6. |
700120551
|
[1] |
SUPPORT
|
HFI
- shield
|
| 7. |
700120553
|
[1] |
SHIELD
|
HFI
- chain
|
| 8. |
700120552
|
[1] |
SUPPORT
|
HFI
- shield
|
| 9. |
700117201
|
[1] |
SUPPORT
|
HFI
- shield
|
| . . |
700013
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 RHSNB
|
| . . |
7700065
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 x 3/4 RHSNB Superseded by part number: 280430
|
| . . |
7883382
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 120M
|
CAS
3/8-16 x 1 HWHMS Superseded by part number: 87034804
|
| . . |
7703432
|
[3] |
BOLT,Hex, Serr, 3/8" - 16 x 3/4"
|
CAS
3/8-16 x 3/4 HFSS Superseded by part number: 255918
|
| . . |
7771470
|
[1] |
BOLT,Hex Serr, 3/8" - 16 x 1 1/4"
|
CAS
3/8-16 x 1-1/4 HFSS Superseded by part number: 86512174
|
| . . |
231-5145
|
[2] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
5/16-18 HFSLN Superseded by part number: 72187067, 145458
|
| . . |
704247
|
[8] |
NUT
|
CAS
3/8-16 HFSLN Superseded by part number: 231-5146, 231-5146, 280736, 231-5146, 280736, 692965, 231-5146, 280736, 692965, 87362
|
