凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (6-18) - BALE CHAMBER SIZING ROLLER ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
177 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700707981
|
[4] |
SCREW,FLAT, 3/4" - 10 x 1-3/4"
|
L
3/4-10 x 1-3/4 HSFCHCS
|
| 2. |
700120608
|
[1] |
STRAP
|
HFI
- reinforcement
|
| 3. |
700120609
|
[1] |
SCRAPER
|
HFI
|
| 4. |
700120598
|
[1] |
ARM
|
HFI
FRAME WA - tensioner, lower
|
| 5. |
219-90
|
[2] |
LUBE NIPPLE,45 Degree Elbow, 1/4" -28 NPTF
|
CAS
1/4-28 x 45deg. ZERK Superseded by part number: 87569
|
| 6. |
700107934
|
[2] |
ROLL
|
IH
ER - idler (includes item 11)
|
| 7. |
700100927
|
[4] |
HUB
|
L
- roller
|
| 8. |
1713155
|
[1] |
FLAP
|
CAS
- counter
|
| 9. |
705533
|
[2] |
WASHER
|
NNA
3/8 HARDENED PLAIN WASHER Superseded by part number: 496-11041, 496-11041, 80702
|
| 10. |
700119915
|
[1] |
PLATE
|
HFI
- reinforcement
|
| 11. |
8050825
|
[4] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
- spherical Superseded by part number: F82059
|
| . . |
703249
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| . . |
700013
|
[5] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
3/8-16 x 3/4 RHSNB
|
| . . |
700047
|
[11] |
BOLT
|
CAS
3/8-16 x 1 RHSNB Superseded by part number: 80280503
|
| . . |
704023
|
[1] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| . . |
704247
|
[16] |
NUT
|
CAS
3/8-16 HFSLN Superseded by part number: 231-5146, 231-5146, 280736, 231-5146, 280736, 692965, 231-5146, 280736, 692965, 87362
|
| . . |
705038
|
[1] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
