凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (6-16) - BELT TENSIONER ROLLERS ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
452 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700707981
|
[6] |
SCREW,FLAT, 3/4" - 10 x 1-3/4"
|
L
3/4-10 x 1-3/4 HSFCHCS
|
| 2. |
700120611
|
[1] |
ARM
|
HFI
FRAME WA - idler
|
| 3. |
700100927
|
[6] |
HUB
|
L
|
| 4. |
700107934
|
[3] |
ROLL
|
IH
ER ASSEMBLY (includes item 6)
|
| 5. |
77040
|
[2] |
FITTING
|
CAS
1/4-28 x 45deg. ZERK Superseded by part number: 219-90, 219-90, 87569
|
| 6. |
8050825
|
[6] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
- cylindrical Superseded by part number: F82059
|
| . . |
7700065
|
[4] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 x 3/4 RHSNB Superseded by part number: 280430
|
| . . |
700047
|
[6] |
BOLT
|
CAS
3/8-16 x 1 RHSNB Superseded by part number: 80280503
|
| . . |
704023
|
[2] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| . . |
704247
|
[10] |
NUT
|
CAS
3/8-16 HFSLN Superseded by part number: 231-5146, 231-5146, 280736, 231-5146, 280736, 692965, 231-5146, 280736, 692965, 87362
|
