神钢零件查询(6D14) - MITSUBISHI DIESEL ENGINE - K904C, K907B, K907C & YS750-2 (1/77-12/06) (06-012) - EXHAUST PIPE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
494 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONMUFFLER |
| 2. | VAME039715 | [2] | U-BOLT | KOBU-BOLT |
| 3. | VAMF430005 | [8] | NUT | KOBNUT 8 Superseded by part number: VAF230008000 |
| . . | VAMF450405 | [4] | WASHER | KOBWASHER,SPG 8 Superseded by part number: 132502A1 |
| 4. | VAME039377 | [1] | BRACKET | KOBBRACKETS, A MUFFLER |
| 4A. | VAME039710 | [1] | BRACKET | KOBBRACKETS, B MUFFLER |
| 5. | VAMH000122 | [4] | BOLT | KOBBOLT,SEAL |
| . . | VAMF450006 | [4] | NUT | KOBWASHER,PLAIN 10 Superseded by part number: 133247A1 |
| 6. | VAMF300857 | [2] | BOLT | KOBBOLT, W/WSR 10X80 |
| 6A. | VAMF244880 | [2] | SCREW | KOBBOLT, W/WSR 10X25 |
| 8. | VAME039717 | [1] | EXHAUST SYSTEM PIPE | KOBPIPE,EXH (FOR M0, M1, M4) Superseded by part number: VAME070395 |
| 8. | VAME039260 | [1] | PIPE,EXH (FOR M3 ) | |
| 9. | VAME032584 | [1] | GASKET | KOBGASKET |
| 11. | VAMH004054 | [3] | NUT | KOB Superseded by part number: 134868A1 |
| 13-15. | VAME027314 | [1] | CLAMP | KOBCLAMP ASSY |
| 13. | VAME027147 | [1] | CLAMP | KOBCLAMP |
| 15. | VAMF101314 | [2] | SCREW | KOBBOLT 12X35 Superseded by part number: VAF103512035 |
| . . | VAMF430007 | [2] | NUT | KOBNUT 12 |
| . . | VAMF450407 | [2] | WASHER WASHER,SPG 12 | WASHER WASHER,SPG 12 |
| 18. | VAME039723 | [1] | PIPE,TAIL (FOR M0), Years: -01-MAY-83 | |
| 18. | VAME039724 | [1] | EXHAUST SYSTEM PIPE | KOBPIPE,TAIL (FOR M1) |
| 18. | VAME039725 | [1] | PIPE,TAIL (FOR M4), Years: -01-MAY-83 | |
| 18. | VAME039726 | [1] | PIPE,TAIL (FOR M3) | |
| 9-20. | VAME039172 | [1] | CLAMP | KOBCLAMP ASSY (FOR M1 & M3) |
| 19. | VAME039173 | [1] | CLAMP (FOR M1 & M3) | |
| 20. | VAMF101314 | [2] | SCREW | KOBBOLT 12X35 (FOR M1 & M3) Superseded by part number: VAF103512035 |
