神钢零件查询(6D14) - MITSUBISHI DIESEL ENGINE - K904C, K907B, K907C & YS750-2 (1/77-12/06) (06-011) - WATER SEPARATOR Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
786 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-11. | VAME039810 | [1] | WATER SEPARATOR ASSY (FOR M0) FF: PARTS | |
| 1-11. | VAME016808 | [1] | WATER SEPARATOR ASSY (FOR M1) | |
| 1. | VAME016809 | [1] | COVER | |
| 2. | VAME016810 | [1] | CASE | |
| 3. | VAME016811 | [1] | NUT,RING | |
| 4. | VAME016813 | [1] | PLATE, BAFFLE | |
| 5. | VAME016814 | [1] | RING,WATER LEVEL | |
| 6. | VAMF520468 | [1] | O-RING,CASE 60 | |
| 7. | VAME016812 | [1] | PLUG | KOBPLUG,DRAIN |
| 8. | VAMF520085 | [1] | O-RING | KOBO-RING 10 Superseded by part number: VAF315101000 |
| 9. | VAMH037087 | [2] | BOLT | KOBBOLT,CONNECTOR |
| 10. | VAMH035069 | [4] | GASKET | KOBGASKET Superseded by part number: 133378A1 |
| 11. | VAMH037116 | [2] | FLEXIBLE JOINT | KOBJOINT,SWIVELING D=10 (FOR M0) |
| 11. | VAMT166055 | [2] | JOINT,SWIVELING D=8 (FOR M1) | |
