凯斯零件查询(8435) - CASE IH SILAGE SPECIAL ROUND BALER (1/97-12/00) (2-22) - AUGER DRIVE ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
899 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700135058
|
[1] |
SPECIAL BOLT
|
HFI
DRAWBOLT WA
|
| 2. |
700135131
|
[2] |
SPROCKET ASSY.
|
HFI
SPROCKET WA - 60B23 tooth
|
| 3. |
61747
|
[2] |
KEY
|
CAS
1/2 X 2-1/2 GIB KEY
|
| 4. |
1791D
|
[1] |
CHAIN (AG),#50, 192 Links x 15.88mm = 3048mm
|
IH
CHAIN - roller, #50 (10 foot bulk)
|
| 5. |
241-1315
|
[1] |
LINK, CONNECTING
|
CAS
LINK - connector, 50# Superseded by part number: 87034815
|
| 6. |
Q3947
|
[1] |
KEY,Gib, 3/8" Sq x 1 1/2"
|
IH
3/8 X 1-1/2 GIB KEY
|
| 7. |
700132455
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET WA - 50B22 tooth (S.N. CFH0124001 thru CFH0124137)
|
| . . |
700147547
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET WA - 50B25 tooth (S.N. CFH0124401 and later)
|
| 8. |
413-1052
|
[1] |
BOLT,Hex, 5/8" - 11 x 3-1/4", Gr 5
|
CAS
5/8-11 X 3-1/4 C Superseded by part number: 9827853
|
| 9. |
396-21066
|
[1] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 10. |
541857R92
|
[1] |
SPROCKET,15T
|
IH
IDLER - sprocket, 15 tooth
|
| 11. |
6619274
|
[1] |
BUSHING
|
HFI
|
| 12. |
241-1316
|
[1] |
LINK,19.05mm Pitch
|
CAS
LINK - connector, #60
|
| 13. |
7086002
|
[1] |
CHAIN (AG)
|
CAS
CHAIN - roller, #60 (10 foot bulk) Superseded by part number: 611362R91X, 241-1316
|
| 14. |
425-108
|
[2] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 15. |
700711557
|
[1] |
WASHER
|
CAS
1/2 HARDENED WIDE PLAIN WASHER
|
