| 1. |
495-81205
|
[2] |
WASHER,32.54mm ID x 50.8mm OD x 1.7mm Thk
|
CAS
1-1/4 X 18 GAUGE NRMB
|
| 2. |
52324
|
[4] |
BUSHING
|
CAS
1-1/4 X 10 GAUGE NRMB Superseded by part number: 052324
|
| 3. |
700716888
|
[3] |
SPROCKET ASSY.
|
CAS
SPROCKET - idler, 17 tooth
|
| 4. |
95-81100
|
[6] |
WASHER,33/64" x 7/8" x .049"
|
CAS
1/2 X 18 GAUGE NRMB Superseded by part number: 86639334
|
| 5. |
396-21066
|
[2] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 6. |
433-828
|
[3] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
1/2-13 X 1-3/4 RHSNB Superseded by part number: 88530
|
| 7. |
231-5348
|
[8] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 8. |
409-7612
|
[4] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 9. |
858167
|
[3] |
SPRING
|
L
- extension
|
| 10. |
700151468
|
[1] |
SHIELD
|
HFI
- auger
|
| 11. |
700147534
|
[1] |
AUGER
|
HFI
WA - left
|
| 12. |
433-620
|
[5] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 13. |
232-5316
|
[20] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 14. |
434-616
|
[7] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 15. |
700135161
|
[2] |
ANGLE
|
HFI
|
| 16. |
433-824
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 X 1-1/2 RHSNB Superseded by part number: 280420, 72187237
|
| 17. |
433-820
|
[2] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 18. |
121-226
|
[8] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 19. |
231-5148
|
[1] |
FLANGE NUT,Flg, USR, 1/2"-13
|
CAS
Superseded by part number: 72187069, 86512371
|
| 20. |
700147515
|
[1] |
SUPPORT
|
HFI
WA
|
| 21. |
565672R92
|
[2] |
SPHERICAL BEARING,1.2505" ID x 72 mm OD x 1"
|
IH
BEARING - spherical Superseded by part number: 84330041
|
| 22. |
617863R1
|
[4] |
FLANGED BEARING
|
IH
|
| 23. |
700135910
|
[1] |
WASHER
|
HFI
- special
|
| 24. |
413-816
|
[1] |
BOLT,Hex, 1/2" - 13 x 1", Gr 5
|
CAS
Superseded by part number: 87909, BN50282
|
| 25. |
700711557
|
[1] |
WASHER
|
CAS
1/2 HARDENED WIDE PLAIN WASHER
|
| 26. |
700147521
|
[1] |
SHIELD
|
HFI
|
| 27. |
700147514
|
[1] |
SUPPORT
|
HFI
|
| 28. |
700147519
|
[1] |
ANGLE
|
HFI
|
| 29. |
700147527
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET WA - 50C18 tooth
|
| 30. |
126-124
|
[1] |
WOODRUFF KEY,#15, 1/4" x 1", HT
|
CAS
Superseded by part number: 47471
|
| 31. |
700147530
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET ASSEMBLY, 50-22 tooth (includes items 32 and 33)
|
| 32. |
586649R92
|
[2] |
BEARING, ROLLER, CYL,31.75mm ID x 62mm OD x 18mm W
|
IH
- cylindrical Superseded by part number: 47577194
|
| 33. |
100-21244
|
[1] |
SNAP RING,2.44", Int, #244
|
CAS
Ring, Snap, 2.44", Int, #244 Superseded by part number: 32324
|
