凯斯零件查询(8435) - CASE IH SILAGE SPECIAL ROUND BALER (1/97-12/00) (2-28) - STUFFER AUGER AND DRIVE ASSEMBLY, RIGHT, SERIAL NUMBER CFH0124001 THROUGH CFH0124137 Case Agriculture_凯斯Case_工程机械

凯斯零件查询(8435) - CASE IH SILAGE SPECIAL ROUND BALER (1/97-12/00) (2-28) - STUFFER AUGER AND DRIVE ASSEMBLY, RIGHT, SERIAL NUMBER CFH0124001 THROUGH CFH0124137 Case Agriculture

广数供应链运营团队, 14 02月, 2025，浏览： 716 次

Pos.	Part No	Qty	Parts name	Comments
1.	111-361	[6]	CARRIAGE BOLT,Short NK, 3/8"-16 x 1 1/2", G5	CAS BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/2", G5 Superseded by part number: 9706752
2.	496-11041	[6]	WASHER,13/32" x 13/16" x .065", HDN	CAS 3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
3.	232-5316	[17]	FLANGE NUT,Flg, 3/8"-16	CAS 3/8-16 HFTLN GR/G Superseded by part number: 86521609
4.	617863R1	[4]	FLANGED BEARING	IH
5.	51292	[2]	SPHERICAL BEARING,1.25" ID x 72 mm OD x 19 mm	IH Superseded by part number: 84330041, 47508357
6.	700132194	[1]	AUGER	HFI WA - right Superseded by part number: 700147548
7.	591514R1	[2]	CARRIAGE BOLT,1/2" - 13 x 2 3/4", Grade 5	IH 1/2-13 X 2-3/4 RHSNB Superseded by part number: 88955
8.	231-5348	[6]	FLANGE NUT,Flg, 1/2"-13	CAS 1/2-13 HFTLN GR/G Superseded by part number: 86521610
9.	434-616	[6]	CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5	CAS 3/8-16 X 1 RHSNB Superseded by part number: 80280503
10.	705566	[2]	WASHER	IH 3/4 HARDENED PLAIN WASHER
11.	705541	[8]	WASHER,0.53" ID x 1.06" OD x 0.14" Thk	CAS 1/2 HARDENED PLAIN WASHER
12.	95-81101	[4]	WASHER,0.52" ID x 0.88" OD x 0.07" Thk	CAS 1/2 X 14 GAUGE NRMB
13.	565442R91	[2]	SPROCKET	IH - idler, 17 tooth Superseded by part number: 87302107
14.	409-7612	[3]	BOLT,3/8"-16 x 1.09" OAL	CAS 3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
15.	700132226	[1]	SHIELD	HFI - right
16.	495-81205	[2]	WASHER,32.54mm ID x 50.8mm OD x 1.7mm Thk	CAS 1-1/4 X 14 GAUGE NRMB
17.	700132223	[1]	SPACER	HFI
18.	700132221	[1]	SPROCKET ASSY.	CAS SPROCKET WA - 50B22 tooth
19.	126-124	[1]	WOODRUFF KEY,#15, 1/4" x 1", HT	CAS Superseded by part number: 47471
20.	700147523	[1]	SUPPORT	HFI WA - right
21.	700132220	[1]	SPACER	HFI
22.	700132214	[1]	PLATE	HFI
23.	700132215	[1]	SPACER	HFI - pivot
24.	433-824	[2]	CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5	CAS 1/2-13 X 1-1/2 RHSNB Superseded by part number: 280420, 72187237
25.	433-816	[2]	CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5	CAS 1/2-13 X 1 RHSNB Superseded by part number: 280486
26.	433-620	[2]	CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5	CAS BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
