| 1. |
433-620
|
[5] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 2. |
232-5316
|
[11] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 3. |
617863R1
|
[4] |
FLANGED BEARING
|
IH
- bearing
|
| 4. |
51292
|
[2] |
SPHERICAL BEARING,1.25" ID x 72 mm OD x 19 mm
|
IH
- spherical Superseded by part number: 84330041, 47508357
|
| 5. |
700147548
|
[1] |
AUGER
|
HFI
WA - right
|
| 6. |
433-840
|
[2] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 2 1/2", Gr 5
|
CAS
1/2-13 X 2-1/2 RHSNB Superseded by part number: 280435
|
| 7. |
231-5348
|
[6] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 8. |
434-616
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 9. |
705541
|
[4] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 10. |
95-81101
|
[6] |
WASHER,0.52" ID x 0.88" OD x 0.07" Thk
|
CAS
1/2 X 14 GAUGE NRMB
|
| 11. |
700716888
|
[2] |
SPROCKET ASSY.
|
CAS
SPROCKET - idler, 17 tooth
|
| 12. |
409-7612
|
[3] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 13. |
700132226
|
[1] |
SHIELD
|
HFI
- right
|
| 14. |
495-81205
|
[2] |
WASHER,32.54mm ID x 50.8mm OD x 1.7mm Thk
|
CAS
1-1/4 X 14 GAUGE NRMB
|
| 15. |
700132223
|
[1] |
SPACER
|
HFI
|
| 16. |
700716889
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET WA - 50B18 tooth
|
| 17. |
126-124
|
[1] |
WOODRUFF KEY,#15, 1/4" x 1", HT
|
CAS
Superseded by part number: 47471
|
| 18. |
700147523
|
[1] |
SUPPORT
|
HFI
WA - right
|
| 19. |
700132220
|
[1] |
SPACER
|
HFI
|
| 20. |
700132214
|
[1] |
PLATE
|
HFI
|
| 21. |
700132215
|
[1] |
SPACER
|
HFI
- pivot
|
| 22. |
433-824
|
[2] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 X 1-1/2 RHSNB Superseded by part number: 280420, 72187237
|
| 23. |
433-820
|
[2] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
