| 1. |
700714786
|
[1] |
SWITCH
|
CAS
- N.O.
|
| 2. |
413-620
|
[2] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
C Hex, 3/8"-16 x 1 1/4", G5, Full Thd Superseded by part number: 72187207, 88011
|
| 3. |
496-11041
|
[2] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 4. |
232-5316
|
[5] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 5. |
700132138
|
[1] |
SUPPORT
|
HFI
- actuator
|
| 6. |
700714795
|
[2] |
ACTUATOR
|
CAS
|
| 7. |
700132137
|
[1] |
SUPPORT
|
HFI
- switch
|
| 8. |
409-7612
|
[3] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 9. |
515-2395
|
[2] |
CLAMP,3/8", Insul, 3/8" Bolt
|
CAS
3/8", Insul, 3/8" Bol, Hose Superseded by part number: 86572009
|
| 10. |
281-13712
|
[2] |
SELF-TAP SCREW,Hex Wash Hd, 1/4" x 3/4"
|
CAS
1/4-20 X 3/4 HWHTCTS
|
| 11. |
700132136
|
[1] |
SUPPORT
|
HFI
- switch
|
| 12. |
700132135
|
[1] |
DISC
|
HFI
- switching
|
| 13. |
700714938
|
[1] |
HARNESS
|
CAS
- wire
|
| 14. |
700132163
|
[1] |
SUPPORT
|
HFI
- actuator
|
| 15. |
700714787
|
[1] |
SWITCH
|
CAS
- SPDT
|
| 16. |
700715032
|
[1] |
SPACER
|
CAS
- 1/4 OD x 1/4 L
|
| 17. |
496-11028
|
[4] |
WASHER,9/32" x 5/8" x .065, HDN
|
CAS
1/4 HARDENED PLAIN WASHER Superseded by part number: 86632587
|
| 18. |
409-748
|
[2] |
BOLT,Hex Flg, 1/4" - 20 x 1/2", Spcl
|
CAS
Superseded by part number: 523291
|
| 19. |
700713208
|
[1] |
SCREW
|
CAS
#6-32 X 2 CRPHMS GR60M
|
| 20. |
492-11006
|
[1] |
LOCK WASHER,#6
|
CAS
Washer, Lock, #6 Superseded by part number: 87276
|
| 21. |
495-31016
|
[2] |
WASHER,#6
|
CAS
Superseded by part number: 86511189
|
| 22. |
225-14106
|
[1] |
NUT,#6-32
|
CAS
Superseded by part number: 88458, 87779111
|
| 23. |
700710208
|
[2] |
ROTARY SWITCH
|
L
SWITCH - assembly
|
| 24. |
700710188
|
[7] |
SCREW
|
CAS
#6-32 X 3/4 CRPHMS STNLS
|
| 25. |
700710187
|
[8] |
WASHER
|
CAS
#6 WPW STNLS
|
| 26. |
700710189
|
[7] |
LOCK NUT
|
CAS
#6-32 LHSN STNLS
|
| 27. |
7883275
|
[1] |
SCREW,Hex Washer, 1/4" - 20 x 3/4"
|
CAS
1/4-20 X 3/4 HWHMS
|
| 28. |
1703354
|
[1] |
NUT
|
IH
1/4-20 HFTLN GR/G
|
| 29. |
515-2179
|
[1] |
CLAMP,5/16", Insul, 1/4" Bolt
|
CAS
Hose 5/16", Insul, 1/4" Bolt Superseded by part number: 237910
|
| 30. |
700710199
|
[6] |
GROMMET
|
CAS
|
| 32. |
515-23190
|
[1] |
CLAMP,3/4", Insul, 3/8" Bolt
|
CAS
Line 3/4", Insul, 3/8" Bolt Superseded by part number: 86624005
|
| 33. |
700709996
|
[1] |
SWITCH
|
IH
ACTUATOR - switch
|
| 34. |
700132133
|
[1] |
PLATE
|
HFI
- switch
|
| 35. |
700714617
|
[1] |
TAPE
|
CAS
- double sided
|
