凯斯零件查询(8435) - CASE IH SILAGE SPECIAL ROUND BALER (1/97-12/00) (4-22) - ELECTRICAL HARNESS SERVICE PARTS (CONTINUED) Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
430 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700715828
|
[1] |
CLAMP
|
CAS
- cable (shell size 13)
|
| 2. |
700709233
|
[1] |
CLAMP
|
CAS
(shell size 11) Superseded by part number: 247725A1
|
| 3. |
700707016
|
[1] |
CAP
|
CAS
- sealing
|
| 4. |
700709232
|
[1] |
POWER SOCKET
|
CAS
RECEPTACLE - standard sex (4 pin)
|
| 5. |
700709704
|
[1] |
WIRE CONNECTOR
|
CAS
PLUG - receptacle (9 pin arrangement) Superseded by part number: 87681908
|
| 6. |
700708079
|
[1] |
WIRE CONNECTOR
|
CAS
RECEPTACLE - standard sex (13-9 pin arrangement) Superseded by part number: 87702796
|
| 7. |
700712896
|
[1] |
SEAL
|
CAS
(shell size 13)
|
| 8. |
700715850
|
[1] |
CONNECTION,ELECTRIC
|
CAS
RECEPTACLE - standard sex (shell size 13)
|
| 9. |
700715341
|
[1] |
PLUG
|
CAS
- 7 pin domestic Superseded by part number: 361428
|
| 10. |
60-6127T2
|
[1] |
CONNECTION
|
L
RING - coupling (#13 plug arrangement)
|
| 11. |
60-6126T2
|
[1] |
CONNECTION
|
L
RING - coupling (#11 plug arrangement) Superseded by part number: 225426C1
|
| 12. |
225153C1
|
[1] |
CONTACT HOUSING
|
IH
CLAMP (shell size 17) Superseded by part number: 84471900
|
| 13. |
700714829
|
[1] |
PLUG
|
CAS
- cavity Superseded by part number: 87686742
|
