| 1. |
218-5105
|
[2] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
- 90 degrees (includes item 22) Superseded by part number: 76344, 72186128
|
| 2. |
700714794
|
[2] |
HYDRAULIC HOSE,0.38" ID x 88.58"
|
CAS
HOSE - hydraulic
|
| 3. |
700129086
|
[1] |
CLAMP
|
HFI
|
| 4. |
746677
|
[2] |
CAP
|
CAS
1/2-14 NPT CAP
|
| 5. |
700129085
|
[1] |
CLAMP
|
CAS
|
| 6. |
433-620
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 7. |
232-5316
|
[4] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 8. |
700120636
|
[2] |
CLAMP
|
HFI
- hose
|
| 9. |
218-5057
|
[2] |
HYD CONNECTOR,9/16" - 18 JIC x 9/16" - 18 ORB
|
CAS
CONNECTOR - short str thread (includes item 22) Superseded by part number: 76350
|
| 10. |
218-5182
|
[1] |
TEE,9/16" - 18 Male JIC x 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
- straight thread branch (includes item 22) Superseded by part number: 163335
|
| 11. |
700132507
|
[1] |
CLAMP
|
HFI
- hose
|
| 12. |
218-5059
|
[2] |
HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring
|
CAS
CONNECTOR, HYD., , Short str thread (Incl. item 23) 3/4"-16, 37º x 3/4"-16, O-Ring Superseded by part number: 128818
|
| 13. |
700714784
|
[1] |
VALVE
|
CAS
ASSEMBLY - bale tension Superseded by part number: 278548, 87035062, 86978349, 86511474, 700715654, 700715666, 87026290, 9625178, 700715674, 700715658, 1272343C2, 700715657, 86508168, 87609274
|
| 14. |
7746456
|
[2] |
PLUG
|
L
- o-ring boss (includes item 22) (used only w/o ejector & monitor)
|
| 15. |
218-5243
|
[3] |
TEE,9/16" - 18 Male JIC x 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
Straight run (Includes item 22) 9/16"-18, 37º x 9/16"-18, O-Ring Run Superseded by part number: 86513020
|
| 16. |
700714823
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 17. |
700715846
|
[1] |
ORNAMENTAL STRIP
|
CAS
TRIM
|
| 18. |
433-632
|
[1] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 2", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 2", G5 Superseded by part number: 280661
|
| 19. |
700714819
|
[1] |
HYDRAULIC HOSE,0.38" ID x 100.39", SAE J516, SAE J343
|
CAS
HOSE - hydraulic
|
| 20. |
111-361
|
[1] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 1 1/2", G5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/2", G5 Superseded by part number: 9706752
|
| 21. |
700715845
|
[1] |
ORNAMENTAL STRIP
|
CAS
TRIM
|
| 22. |
738468
|
[13] |
O-RING
|
IH
|
| 23. |
237-6008
|
[2] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
CAS
8-1, 90 Duro, .644" ID x .087" Thk Superseded by part number: 128825
|
| 24. |
700714707
|
[2] |
CYLINDER
|
CAS
ASSEMBLY - hydraulic
|
| 25. |
218-5135
|
[1] |
ELBOW,45 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
- 45 degrees (includes item 22) Superseded by part number: 330346
|
| 26. |
700714820
|
[1] |
HYDRAULIC HOSE,0.25" ID x 18.11", SAE J516, SAE J343
|
CAS
HOSE - hydraulic
|
| 27. |
700714793
|
[1] |
HYDRAULIC HOSE,0.25" ID x 92.52", SAE J516, SAE J343
|
CAS
HOSE - hydraulic
|
| 28. |
700714822
|
[1] |
HYDRAULIC HOSE,0.38" ID x 110.24", SAE J517, SAE J516, SAE J343
|
CAS
HOSE - hydraulic
|
