凯斯零件查询(8435) - CASE IH SILAGE SPECIAL ROUND BALER (1/97-12/00) (6-10) - BALE TENSIONING ASSEMBLY, LOWER, SERIAL NUMBER CFH0124001 THROUGH CFH0124137 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
493 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700132379
|
[2] |
PIN
|
HFI
|
| 2. |
432-1020
|
[6] |
COTTER PIN,5/32" x 1 1/4"
|
CAS
PIN, SPLIT (COTTER), 5/32" x 1 1/4" Superseded by part number: 86523851
|
| 3. |
705566
|
[4] |
WASHER
|
IH
3/4 HARDENED PLAIN WASHER
|
| 4. |
700132377
|
[2] |
SUPPORT
|
HFI
WA - lower
|
| 5. |
700132382
|
[2] |
SPACER
|
HFI
|
| 6. |
396-21066
|
[2] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 7. |
700716026
|
[2] |
PIN
|
CAS
5/8 X 2-1/4 CLEVIS PIN
|
| 8. |
700707981
|
[4] |
SCREW,FLAT, 3/4" - 10 x 1-3/4"
|
L
3/4-10 X 1-3/4 HSFCHCS, special
|
| 9. |
700132380
|
[2] |
ROLLER
|
HFI
ASSEMBLY (includes items 11, 12, 14 and 15)
|
| 10. |
700118652
|
[4] |
WASHER
|
CAS
- special
|
| 11. |
700715063
|
[4] |
TAPE
|
CAS
- adhesive
|
| 12. |
700132354
|
[12] |
SLEEVE
|
CAS
|
| 13. |
700132361
|
[1] |
ARM
|
HFI
WA - lower
|
| 14. |
700118709
|
[1] |
SHAFT
|
HFI
|
| 15. |
8050825
|
[4] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
- cylindrical Superseded by part number: F82059
|
| 16. |
121-226
|
[8] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 17. |
232-5316
|
[8] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 18. |
413-888
|
[2] |
BOLT,Hex, 1/2" - 13 x 5-1/2", Gr 5
|
CAS
.5 X 5.5 UNC GR5 YZD Superseded by part number: 88576
|
| 19. |
231-5348
|
[2] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
