凯斯零件查询(8435) - CASE IH SILAGE SPECIAL ROUND BALER (1/97-12/00) (6-22) - TWINE BOX ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
709 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700132476
|
[1] |
GUARD
|
HFI
- lower, twine
|
| 2. |
700132474
|
[1] |
SUPPORT
|
HFI
- lower, twine
|
| 3. |
409-7612
|
[12] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 4. |
232-5316
|
[13] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 5. |
700132473
|
[1] |
SUPPORT
|
HFI
- upper, twine
|
| 6. |
6868459
|
[6] |
DIVIDER
|
HFI
|
| 7. |
6549869
|
[4] |
SUPPORT
|
L
BRACKET - tension
|
| 8. |
700132477
|
[1] |
SUPPORT
|
HFI
WA - upper
|
| 9. |
413-444
|
[4] |
BOLT,Hex, 1/4" - 20 x 2-3/4", Gr 5
|
CAS
1/4-20 X 2-3/4 C Superseded by part number: 72187194, 280566
|
| 10. |
496-11028
|
[4] |
WASHER,9/32" x 5/8" x .065, HDN
|
CAS
1/4 HARDENED PLAIN WASHER Superseded by part number: 86632587
|
| 11. |
232-4114
|
[4] |
LOCK NUT,1/4"-20, GC
|
CAS
1/4-20 HTLN GR B Superseded by part number: 280129
|
| 12. |
700707677
|
[4] |
SPRING
|
L
- compression
|
| 13. |
700132475
|
[1] |
GUARD
|
HFI
- upper, twine
|
| 14. |
121-115
|
[6] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 15. |
232-5315
|
[6] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 16. |
121-226
|
[1] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
