凯斯零件查询(8435) - CASE IH SILAGE SPECIAL ROUND BALER (1/97-12/00) (6-24) - BALE COUNTER AND SUPPORT ASSEMBLIES Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
584 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
6179832
|
[1] |
SPACER
|
CAS
|
| 2. |
700133796
|
[1] |
ROD
|
HFI
WA
|
| 3. |
496-81010
|
[1] |
WASHER
|
CAS
3/8 HARDENED WIDE PLAIN WASHER Superseded by part number: 86625244
|
| 4. |
121-226
|
[3] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 5. |
232-5316
|
[3] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 6. |
700707437
|
[1] |
COUNTER
|
CAS
- bale
|
| 7. |
413-412
|
[2] |
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5
|
CAS
Superseded by part number: 9707580, 72187189
|
| 8. |
231-5144
|
[2] |
SERRATED NUT,Flg, USR, 1/4"-20
|
CAS
Superseded by part number: 523282, 72187066
|
| 9. |
700710049
|
[1] |
WASHER
|
CAS
3/8 FENDER WASHER, PLATED
|
| 10. |
700716224
|
[1] |
FLAP
|
HFI
- counter
|
| 11. |
700710187
|
[4] |
WASHER
|
CAS
#6 PLAIN WASHER - special
|
| 12. |
700135139
|
[1] |
ANGLE
|
HFI
|
