| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 132-9830 | [1] | GAUGE AS-OIL LEVEL(DIPSTICK)(ENGINE) | |
| 2. | 183-9329 | [1] | TUBE AS | |
| 3. | 209-7309J | [3] | PLUG | |
| 4. | 3E-4353 | [1] | WASHER-HARD(11X25X3-MM THK) | |
| 5. | 228-4947 | [1] | SEAL-O-RING | |
| 6. | 6V-6317M | [1] | BOLT(M10X1.5X20-MM) | |
| 7. | 7X-0613 | [3] | WASHER-HARD(8.8X25.5X5-MM THK) | |
| 8. | 9N-0869 | [1] | WASHER-HARD(8.8X25.5X2-MM THK) | |
| J | USE TO PLUG OPTIONAL DIPSTICK LOCATIONS | |||
| M | METRIC PART | |||
