凯斯零件查询(8435) - CASE IH SILAGE SPECIAL ROUND BALER (1/97-12/00) (7-18) - TONGUE SHIELDS AND LATCH SUPPORT ASSEMBLIES, LEFT, SERIAL NUMBER CFH0124001 THROUGH CFH0124137 Case Agriculture_凯斯Case_工程机械

凯斯零件查询(8435) - CASE IH SILAGE SPECIAL ROUND BALER (1/97-12/00) (7-18) - TONGUE SHIELDS AND LATCH SUPPORT ASSEMBLIES, LEFT, SERIAL NUMBER CFH0124001 THROUGH CFH0124137 Case Agriculture

广数供应链运营团队, 14 02月, 2025，浏览： 342 次

Pos.	Part No	Qty	Parts name	Comments
1.	340-1108	[4]	SCREW,Cross Pan Hd, #10-24 x 1/2"	CAS #10-24 X 1/2 CRPHMS GR 60M
2.	195-513	[4]	WASHER,#10	CAS PLAIN WASHER #10 Superseded by part number: 9824326
3.	492-11010	[4]	LOCK WASHER,#10	CAS WASHER, LOCK, #10 Superseded by part number: 80684
4.	225-14110	[4]	NUT,#10-24	CAS Superseded by part number: 87304
5.	121-237	[2]	SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl	CAS 3/8-16 X 1-1/4 HFS GR8 Superseded by part number: 87327172
6.	232-5316	[29]	FLANGE NUT,Flg, 3/8"-16	CAS 3/8-16 HFTLN GR/G Superseded by part number: 86521609
7.	409-7612	[27]	BOLT,3/8"-16 x 1.09" OAL	CAS 3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
8.	700132467	[1]	SUPPORT	HFI - latch
9.	700117068	[2]	SUPPORT	HFI
10.	700132470	[1]	SHIELD	HFI - lower, left (includes decal)
11.	121-115	[6]	SERRATED BOLT,Hex, 5/16" - 18 x 3/4"	CAS
12.	232-5315	[11]	FLANGE NUT,Flg, 5/16"-18	CAS 5/16-18 HFTLN GR/G
13.	700135132	[1]	SHIELD	HFI
14.	121-108	[1]	BOLT,Hex Flg, 5/16"-18 x 1 1/4", Serr	CAS 5/16-18 X 1 HWHMS
15.	700132466	[1]	SHIELD	HFI
16.	700132465	[1]	HINGE	HFI WA - right
17.	281-34912	[4]	SELF-TAP SCREW,Hex Washer, 3/8" - 16 x 3/4"	CAS 3/8-16 X 3/4 HWHTCTS
18.	700132462	[1]	HINGE	HFI WA - left
19.	700135157	[1]	COVER	HFI
20.	700132486	[1]	SUPPORT	HFI - upper
21.	413-512	[4]	BOLT,Hex, 5/16" - 18 x 3/4", Gr 5	CAS C Hex, 5/16"-18 x 3/4", G5, Full Thd Superseded by part number: 72187196, 87872
22.	700132487	[1]	SHIELD	HFI
23.	700132460	[2]	SUPPORT	HFI - hinge
24.	700115914	[1]	PIN	CAS
25.	280-5488	[2]	SELF-TAP SCREW,Hex Wash Hd, 5/16" x 1/2"	CAS 5/16-18 X 1/2 HWHTCTS
26.	700133810	[1]	SHIELD	HFI ASSEMBLY - upper, left (includes decals)
27.	700715104	[4]	BUMPER	CAS
28.	700714529	[2]	SOCKET/RECEPTACLE	CAS RECEPTACLE Superseded by part number: 292504A1
29.	700132526	[1]	SUPPORT	HFI - latch
