凯斯零件查询(8435) - CASE IH SILAGE SPECIAL ROUND BALER (1/97-12/00) (7-20) - TONGUE SHIELDS AND LATCH SUPPORT ASSEMBLIES, LEFT, SERIAL NUMBER CFH0124401 AND LATER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
895 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
409-7612
|
[10] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 2. |
232-5316
|
[30] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 3. |
700715104
|
[8] |
BUMPER
|
CAS
|
| 4. |
121-237
|
[4] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
3/8-16 X 1-1/4 HFS GR8 Superseded by part number: 87327172
|
| 5. |
700135963
|
[1] |
SHIELD
|
HFI
- lower, left (includes decal)
|
| 6. |
121-115
|
[10] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 7. |
232-5315
|
[15] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 8. |
700135132
|
[1] |
SHIELD
|
HFI
|
| 9. |
121-108
|
[1] |
BOLT,Hex Flg, 5/16"-18 x 1 1/4", Serr
|
CAS
5/16-18 X 1 HWHMS
|
| 10. |
700132466
|
[1] |
SHIELD
|
HFI
|
| 11. |
700132465
|
[1] |
HINGE
|
HFI
WA - right
|
| 12. |
281-34912
|
[4] |
SELF-TAP SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
3/8-16 X 3/4 HWHTCTS
|
| 13. |
700132462
|
[1] |
HINGE
|
HFI
WA - left
|
| 14. |
700135157
|
[1] |
COVER
|
HFI
|
| 15. |
700147588
|
[1] |
SUPPORT
|
HFI
- upper
|
| 16. |
121-226
|
[16] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 17. |
413-512
|
[4] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
CAS
C Hex, 5/16"-18 x 3/4", G5, Full Thd Superseded by part number: 72187196, 87872
|
| 18. |
700132487
|
[1] |
SHIELD
|
HFI
|
| 19. |
700132460
|
[2] |
SUPPORT
|
HFI
- hinge
|
| 20. |
700115914
|
[1] |
PIN
|
CAS
|
| 21. |
280-5488
|
[2] |
SELF-TAP SCREW,Hex Wash Hd, 5/16" x 1/2"
|
CAS
5/16-18 X 1/2 HWHTCTS
|
| 22. |
700147590
|
[1] |
SHIELD
|
HFI
- upper, left (includes decals)
|
