凯斯零件查询(8435) - CASE IH SILAGE SPECIAL ROUND BALER (1/97-12/00) (7-26) - SHIELD, LATCH AND SUPPORT ASSEMBLIES, LEFT, SERIAL NUMBER CFH0124001 THROUGH CFH0124137 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
945 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
440-13112
|
[13] |
SCREW,Cross Pan Hd, 5/16"-18 x 3/4"
|
CAS
5/16-18 X 3/4 CRPHMS GR 60M Superseded by part number: 86511938
|
| 2. |
231-5145
|
[32] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 3. |
700133805
|
[1] |
SHIELD
|
HFI
ASSEMBLY - lower, left (includes decal)
|
| 4. |
439-5532
|
[2] |
HEADED PIN,5/16" x 2"
|
CAS
5/16 X 2 CLEVIS PIN
|
| 5. |
495-61034
|
[3] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
5/16 WIDE PLAIN WASHER
|
| 6. |
700714706
|
[2] |
LATCH
|
CAS
- 90 degree turn
|
| 7. |
700117061
|
[2] |
LATCH
|
CAS
- strap
|
| 8. |
121-115
|
[15] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 9. |
700133812
|
[1] |
SHIELD
|
HFI
ASSEMBLY - lower, left (includes decal)
|
| 10. |
700117058
|
[2] |
SUPPORT
|
CAS
PIN - locating
|
| 11. |
432-812
|
[4] |
COTTER PIN,3/4" OAL x 1/8" W
|
CAS
PIN, SPLIT (COTTER), 1/8" x 3/4" Superseded by part number: 80756
|
| 12. |
754606
|
[2] |
SPRING
|
CAS
- compression
|
| 13. |
700117067
|
[2] |
SUPPORT
|
CAS
ROD - support
|
| 14. |
256873
|
[4] |
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
|
NH
|
| 15. |
700132503
|
[1] |
CHANNEL
|
HFI
|
| 16. |
700132535
|
[1] |
BRACE
|
HFI
- wa, left, lower
|
| 17. |
700132529
|
[1] |
BRACE
|
HFI
- wa, left, upper
|
| 18. |
700132488
|
[1] |
SHIELD
|
HFI
- upper, left
|
