| 1. |
121-226
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 2. |
231-5146
|
[2] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 3. |
432-812
|
[4] |
COTTER PIN,3/4" OAL x 1/8" W
|
CAS
PIN, SPLIT (COTTER), 1/8" x 3/4" Superseded by part number: 80756
|
| 4. |
700132502
|
[1] |
ANCHOR
|
HFI
- lower
|
| 5. |
433-512
|
[4] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 6. |
231-5145
|
[38] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 7. |
121-115
|
[17] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 8. |
700117058
|
[2] |
SUPPORT
|
CAS
PIN - locating
|
| 9. |
700132493
|
[1] |
SHIELD
|
HFI
- lower, right
|
| 10. |
440-13112
|
[13] |
SCREW,Cross Pan Hd, 5/16"-18 x 3/4"
|
CAS
5/16-18 X 3/4 CRPHMS GR 60M Superseded by part number: 86511938
|
| 11. |
700133814
|
[1] |
SHIELD
|
HFI
ASSEMBLY - lower, right (includes decal)
|
| 12. |
495-61034
|
[3] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
5/16 WIDE PLAIN WASHER
|
| 13. |
700133803
|
[1] |
SHIELD
|
HFI
ASSEMBLY - lower, right (includes decal)
|
| 14. |
700132503
|
[1] |
CHANNEL
|
HFI
|
| 15. |
700714706
|
[2] |
LATCH
|
CAS
- 90 degree turn
|
| 16. |
439-5532
|
[2] |
HEADED PIN,5/16" x 2"
|
CAS
5/16 X 2 CLEVIS PIN
|
| 17. |
256873
|
[4] |
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
|
NH
|
| 18. |
700132489
|
[1] |
SHIELD
|
HFI
- upper, right
|
| 19. |
700132534
|
[1] |
BRACE
|
HFI
- wa, right, upper
|
| 20. |
700132537
|
[1] |
BRACE
|
HFI
- wa, right, lower
|
| 21. |
700117067
|
[2] |
SUPPORT
|
CAS
ROD - support
|
| 22. |
754606
|
[2] |
SPRING
|
CAS
- compression
|
| 23. |
700132501
|
[1] |
ANCHOR
|
HFI
- upper
|
| 24. |
700117061
|
[2] |
LATCH
|
CAS
|
