凯斯零件查询(8435) - CASE IH SILAGE SPECIAL ROUND BALER (1/97-12/00) (7-32) - SHIELD, LATCH AND SUPPORT ASSEMBLIES, RIGHT, SERIAL NUMBER CFH0124401 AND LATER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
1029 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
121-226
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 2. |
232-5316
|
[8] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 3. |
432-812
|
[4] |
COTTER PIN,3/4" OAL x 1/8" W
|
CAS
PIN, SPLIT (COTTER), 1/8" x 3/4" Superseded by part number: 80756
|
| 4. |
700132502
|
[1] |
ANCHOR
|
HFI
- lower
|
| 5. |
700132493
|
[1] |
SHIELD
|
HFI
- lower, right
|
| 6. |
433-512
|
[4] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 7. |
231-5145
|
[39] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 8. |
232-5315
|
[1] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 9. |
121-115
|
[28] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 10. |
700135648
|
[2] |
PIN
|
HFI
WA
|
| 11. |
700147586
|
[1] |
CHANNEL
|
HFI
|
| 12. |
700147584
|
[1] |
SHIELD
|
HFI
WA - lower, right
|
| 13. |
495-61034
|
[3] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
5/16 WIDE PLAIN WASHER
|
| 14. |
700135878
|
[1] |
SHIELD
|
HFI
- lower, right
|
| 15. |
440-13112
|
[8] |
SCREW,Cross Pan Hd, 5/16"-18 x 3/4"
|
CAS
5/16-18 X 3/4 CRPHMS GR 60M Superseded by part number: 86511938
|
| 16. |
700135650
|
[2] |
HANDLE
|
HFI
|
| 17. |
439-5532
|
[2] |
HEADED PIN,5/16" x 2"
|
CAS
5/16 X 2 CLEVIS PIN
|
| 18. |
700135960
|
[1] |
SHIELD
|
HFI
- upper, right
|
| 19. |
700132534
|
[1] |
BRACE
|
HFI
WA - R, upper
|
| 20. |
700132537
|
[1] |
BRACE
|
HFI
WA - R, lower
|
| 21. |
700132503
|
[1] |
CHANNEL
|
HFI
|
| 22. |
700117067
|
[2] |
SUPPORT
|
CAS
|
| 23. |
754606
|
[2] |
SPRING
|
CAS
- compression
|
| 24. |
700117061
|
[2] |
LATCH
|
CAS
|
| 25. |
700132501
|
[2] |
ANCHOR
|
HFI
- upper
|
| 26. |
409-7612
|
[6] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
