神钢零件查询(6D14) - MITSUBISHI DIESEL ENGINES - K907D & K907LC EXCAVATORS (1/86-12/06) (06-001) - RADIATOR HOSE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
269 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 5. | VAMH020015 | [1] | CLIP | KOBCLAMP,HOSE 60,FOR M4 ONLY Superseded by part number: VAMH020383 |
| 5. | VAMH020386 | [1] | CLAMP | KOBCLAMP,HOSE 75,FOR M4 ONLY |
| 5. | VAMH020388 | [1] | CLIP | KOBCLAMP,HOSE 85,FOR M4 ONLY |
| 6. | VAMH020013 | [9] | HOSE CLAMP | KOBCLAMP,HOSE 65,FOR M4 ONLY Superseded by part number: VAMH020384 |
| 12. | VA3184792500 | [1] | STAY,SUCTION PIPE,FOR M6 ONLY | |
| 13. | VAMH000713 | [2] | BOLT | KOBBOLT,FLANGE 10X20,FOR M6 ONLY, Start Year: 01-OCT-84 |
| 13. | VAMF300841 | [2] | SCREW | KOBB0LT,W/WSR 10X20,FOR M6 ONLY, Years: -01-DEC-83 Superseded by part number: 132461A1 |
