神钢零件查询(6D14) - MITSUBISHI DIESEL ENGINES - K907D & K907LC EXCAVATORS (1/86-12/06) (06-002) - EXHAUST PIPE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
785 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 9. | VAME063946 | [1] | SEAL RETAINER | KOBRING,SEAL,FOR M9 ONLY Superseded by part number: 134995A1 |
| 41. | VAME032584 | [1] | GASKET | KOBGASKET,FOR M4 ONLY |
| 42. | VAME063737 | [1] | GASKET | KOBGASKET,FOR M4 ONLY |
| 43. | VAME039325 | [1] | GASKET | KOBGASKET,FOR M5 ONLY |
| 44. | VAMH000122 | [2] | BOLT | KOBBOLT,SEAL,FOR M5 ONLY |
| 45. | VAMH000399 | [3] | SCREW | KOBBOLT 8X16,FOR M5 ONLY |
