凯斯零件查询(8440) - CASE IH ROUND BALER (1/88-12/90) (25[2]) - ACTUATOR ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
713 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700704928
|
[1] |
SCREW
|
IH
JACKSCREW AND BRAKE ASSEMBLY Superseded by part number: 91232C1
|
| 2. |
700704926
|
[1] |
TUBE
|
IH
- cover Superseded by part number: 91228C1
|
| 3. |
1714088
|
[1] |
SCREW - special (5)
|
|
| 4. |
700704853
|
[1] |
HOUSING
|
HFI
- front Superseded by part number: 1281488C1
|
| 5. |
700704927
|
[1] |
CLUTCH
|
IH
- assembly Superseded by part number: 1281485C1
|
| 6. |
700704854
|
[1] |
HOUSING
|
HFI
- rear
|
| 7. |
700704861
|
[1] |
GEAR
|
HFI
(INTERMEDIATE) AND WASHER Superseded by part number: 1281484C1
|
| 8. |
700704871
|
[1] |
MOTOR, ELECTRIC
|
HFI
MOTOR
|
| . . |
700704856
|
[1] |
SEAL KIT
|
HFI
O-RING AND SEAL REPAIR KIT, Includes items in art marked with asterisk. Superseded by part number: 1281489C1
|
