| 1. |
6549547
|
[2] |
SPACER
|
HFI
13/16 I.D. x 3-19/32" long
|
| 2. |
6549489
|
[1] |
MOUNTING PARTS
|
HFI
MOUNT - left
|
| 3. |
6549554
|
[2] |
PIPE
|
HFI
- lock trip
|
| 4. |
7892326
|
[2] |
TUBE ASSY.,9.53" OD, 750, 90 mm Length
|
HFI
LINE - hydraulic, 9/16-18 JIC (2) F/F, 72" long
|
| 5. |
6546469
|
[2] |
STOP
|
HFI
- safety
|
| 6. |
63644
|
[2] |
CLEVIS PIN
|
CAS
3/8 x 2-1/8 CLEVIS PIN
|
| 7. |
7073729
|
[2] |
HYDRAULIC HOSE,0.38" ID x 52.00", SAE 100R1
|
CAS
HOSE - hydraulic, 9/16-18 JIC x 3/8-18 NPTF, M/M, 52" long
|
| 8. |
7892318
|
[2] |
TUBE ASSY.,9.53 mm OD, 830, 180 mm Length
|
HFI
LINE - hydraulic, 9/16-18 JIC (2) F/F, 39-3/4" long
|
| 9. |
746743
|
[2] |
TEE
|
IH
9/16-18 JIC (3) FEMALE FLARED TEE Superseded by part number: 76355
|
| 10. |
791038
|
[4] |
ELBOW
|
CAS
9/16-18 JIC x 9/16-18 JIC M/M x 90deg. ELBOW Superseded by part number: 241074
|
| 11. |
7892300
|
[2] |
TUBE ASSY.,9.53 mm OD, 776, 115 mm Length
|
HFI
LINE - hydraulic, 9/16-18 JIC (2) F/F, 35" long
|
| 12. |
7892334
|
[4] |
TUBE ASSY.
|
HFI
LINE - hydraulic, 9/16-18 JIC (2) F/F, 34-1/4" long, pipe length from end to end is approx. 6 feet
|
| 13. |
6251375
|
[7] |
CLAMP
|
HFI
- line, hydraulic
|
| 14. |
6251367
|
[2] |
CLAMP
|
HFI
- hose, hydraulic
|
| 15. |
6514863
|
[2] |
PLATE
|
HFI
- decal, danger
|
| 16. |
7892284
|
[2] |
CYLINDER
|
HFI
- hydraulic
|
| 17. |
87415
|
[2] |
LUBE NIPPLE,90 Degree, 1/4" NPT x 3/4" L, Drive
|
NH
1/4-28 x 90deg. ZERK
|
| 18. |
6549588
|
[2] |
SPACER
|
CAS
1-5/16 I.D. x 1" long
|
| 19. |
6549497
|
[1] |
MOUNTING PARTS
|
HFI
MOUNT - right
|
| 20. |
52324
|
[2] |
BUSHING
|
CAS
1-1/4 x 10 GAUGE MACHINERY BUSHING Superseded by part number: 052324
|
| 21. |
62349
|
[2] |
LOCK WASHER
|
NNA
.149 HAIR PIN COTTER Superseded by part number: 87790435, 87790435, 9966809, 87790435, 9966809, S120261
|
| 22. |
7892292
|
[2] |
HOSE ASSY.
|
HFI
HOSE - hydraulic 9/16-18 JIC x 1/4-18 NPTF, M/M, 42-1/8" long
|
| 23. |
8742470
|
[2] |
HYDRAULIC HOSE,6.35 mm ID x 800.00 mm, SAE 100R1 TYPE - T
|
HFI
1/4 NPTF x 9/16-18 JIC 6.35 mm ID x 800.00 mm, SAE 100R1 TYPE - T
|
| . . |
702035
|
[5] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 x 1-1/4 HEX CAP SCREW GRADE 5
|
| . . |
7701659
|
[2] |
BOLT,Hex, 5/8" - 11 x 2 1/2", Gr 5
|
CAS
5/8-11 x 2-1/2 HEX CAP SCREW GRADE 5 Superseded by part number: 280233
|
| . . |
413-1056
|
[2] |
BOLT,Hex, 5/8" - 11 x 3-1/2", Gr 5
|
CAS
5/8-11 x 3-1/2 HEX CAP SCREW GRADE 5 Superseded by part number: 280119
|
| . . |
7883002
|
[2] |
BOLT,Hex 3/4" - 10 x 5 1/2", Gr 5
|
CAS
3/4-10 x 5-1/2 HEX CAP SCREW GRADE 5 Superseded by part number: 86507002
|
| . . |
704700
|
[4] |
SUPPORT
|
NNA
5/8-11 HEX CENTER LOCK NUT Superseded by part number: 230-42110
|
