凯斯零件查询(8440) - CASE IH ROUND BALER (1/88-12/90) (26[2]) - WHEEL AND AXLE ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
191 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
712166
|
[1] |
CONE
|
CAS
- bearing, outer Superseded by part number: 86516471
|
| 2. |
026690
|
[1] |
HUB
|
CAS
ASSEMBLY (includes bearing cups)
|
| 3. |
6546345
|
[1] |
SPINDLE
|
HFI
|
| 4. |
744193
|
[1] |
SEAL
|
CAS
Superseded by part number: 491715R91
|
| 5. |
300426R91
|
[1] |
BEARING ASSY,45.618 mm ID x 25.4 mm
|
IH
- bearing, inner Superseded by part number: 512725
|
| 6. |
712182
|
[1] |
BEARING CUP,3.265" OD
|
CAS
CUP - bearing, inner Superseded by part number: 86900365
|
| 7. |
712208
|
[1] |
CUP
|
CAS
- bearing, outer Superseded by part number: 86516462
|
| 8. |
700707924
|
[1] |
RIM
|
CAS
WHEEL, 15" Superseded by part number: A57879
|
| 9. |
26674
|
[1] |
CAP
|
NNA
- hub Superseded by part number: 137395, 137395, D143405
|
| 10. |
T52730
|
[6] |
WHEEL BOLT
|
IH
9/16-18 x 1-1/8" long Superseded by part number: 86628557
|
| 11. |
704650
|
[1] |
NUT
|
CAS
7/8-14 SLOTTED HEX NUT Superseded by part number: 425-1314
|
