| 1. |
6469811
|
[2] |
PIPE
|
HFI
|
| 2. |
7058126
|
[2] |
SPRING
|
HFI
- compression
|
| 3. |
758961
|
[2] |
SPRING
|
HFI
|
| 4. |
6548424
|
[1] |
ARM ASSY.
|
HFI
ARM - left
|
| 5. |
6548721
|
[2] |
BUSHING
|
HFI
2-5/8 I.D. x 3-15/16" long
|
| 6. |
6566145
|
[2] |
STRAP
|
HFI
SHAFT Superseded by part number: 700122884
|
| 7. |
216937
|
[2] |
FRAME
|
HFI
5/8" I.D. x 2-1/2" long Superseded by part number: NLS
|
| 8. |
1661320
|
[2] |
SPRING
|
HFI
ANCHOR - spring
|
| 9. |
7058910
|
[4] |
SPRING
|
L
|
| 10. |
6488639
|
[2] |
STRAP
|
HFI
|
| 11. |
6548085
|
[1] |
ROLLER
|
HFI
|
| 12. |
700708091
|
[2] |
SPHERICAL BEARING,34.93 mm ID x 72 mm OD x 38.89 mm
|
CAS
BEARING - spherical Superseded by part number: 47577188, 47066
|
| 13. |
617863R1
|
[4] |
FLANGED BEARING
|
IH
|
| 14. |
1661319
|
[1] |
ARM/LIFTING DEVICE
|
HFI
ARM
|
| 15. |
6548697
|
[2] |
BUSHING
|
HFI
3/4 I.D. x 3-3/8" long
|
| 16. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 17. |
6566038
|
[2] |
ROD
|
HFI
|
| 18. |
6472351
|
[6] |
BUSHING
|
HFI
5/8 I.D. x 17/32" long
|
| 19. |
6548432
|
[1] |
ARM ASSY.
|
HFI
ARM - right
|
| 20. |
6548549
|
[2] |
ROD
|
HFI
|
| 21. |
6548358
|
[1] |
GRATE ASSY.
|
HFI
GRID
|
| 22. |
6566111
|
[1] |
PIPE
|
HFI
Superseded by part number: 700122885
|
| 23. |
7894553
|
[2] |
KNOB
|
HFI
|
| . . |
772418
|
[2] |
BOLT,Hex, 5/16" x 3 1/2", Gr 5
|
CAS
5/16-18 x 3-1/2 HEX CAP SCREW GRADE 5 Superseded by part number: 413-556, 413-556, 86507008
|
| . . |
701235
|
[2] |
BOLT,1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 x 1-1/2 HEX CAP SCREW GRADE 5
|
| . . |
703983
|
[4] |
BOLT,Hex, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
1/2-13 x 1-3/4 HEX CAP SCREW GRADE 5
|
| . . |
773374
|
[2] |
BOLT,Hex, 1/2" x 3 1/2", Gr 5
|
CAS
1/2-13 x 3-1/2 HEX CAP SCREW GRADE 5 Superseded by part number: 9637417
|
| . . |
7701733
|
[2] |
SPECIAL BOLT
|
HFI
5/8-11 x 6 FULL THREAD HEX CAP SCREW GRADE 5
|
| . . |
703660
|
[2] |
BOLT,Hex 3/4" - 10 x 5", Gr 5
|
CAS
3/4-10 x 5 HEX CAP SCREW GRADE 5 Superseded by part number: 88421
|
| . . |
7700065
|
[6] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 x 3/4 ROUND HEAD SQUARE NECK BOLT GRADE 5 Superseded by part number: 280430
|
| . . |
704635
|
[4] |
NUT
|
CAS
3/8-16 HEX CENTER LOCK NUT Superseded by part number: 230-4216, 230-4216, 88902
|
| . . |
704163
|
[2] |
LOCK NUT
|
CAS
5/16-18 HEX TOP LOCK NUT Superseded by part number: 230-4145
|
| . . |
704858
|
[6] |
LOCK NUT
|
CAS
1/2-13 HEX TOP LOCK NUT Superseded by part number: 230-4118
|
